Connectors
13.
Connectors
13.1.
Under the cable cover
Fig. 13.1: External connectors under the cable cover
Pin assignment
Power supply
1 x RSMA (optional)
1 x SMA (optional)
USB0, USB1, USB2, USB3
RJ45
COM1, COM2
DLT-V72 Operating Instructions V2.50 Preliminary
12/24/48 VDC nominal
Remote Wi-Fi antenna
Remote WWAN antenna
USB 2.0 interfaces (HI-SPEED™), bootable
LAN Ethernet 10/100/1000 MBit/s
Serial interfaces
111 / 140
