6.2.2.

Available Radio cards for WWAN

USA: QUECTEL EC25A
Europe: QUECTEL EC25E
Card type
Technology
FCCID
Maximum transmitting power
26 / 140
Technical data – Radio modules (all optional)
WWAN PCIe Full-Mini Card
WWAN 2G, 3G, 4G cellular bands and GNSS
FCC ID: XMR201605EC25A
(valid for the EC25-A variant)
Class 3 (23dBm±2dB) for LTE FDD
Class 3 (23dBm±2dB) for LTE TDD
Class 3 (24dBm+1/-3dB) for TD-SCDMA
Class 3 (24dBm+1/-3dB) for WCDMA
Class E2 (27dBm±3dB) for EDGE 850/900MHz
Class E2 (26dBm+3/-4dB) for EDGE
1800/1900MHz
Class 4 (33dBm±2dB) for GSM 850/900MHz
Class 1 (30dBm±2dB) for GSM 1800/1900MHz
