Technical data – Device
5. Technical data – Device
5.1.

General

CPU
Chipset
Cache
RAM
BIOS
Real-time clock
CFast
Weight, material
DLT-V7210 P
DLT-V7210 R
DLT-V7210 D
DLT-V7212 P
DLT-V7212 R
DLT-V7212 D
DLT-V7210 K
DLT-V7210 KD
DLT-V7212 P+
Battery pack
Material
Display
DLT-V7210
DLT-V7212
DLT-V7210 K
DLT-V7210 KD
DLT-V7212 P+
The LCD display of the DLT-V72 series fulfills the highest quality standards and was inspected for pixel
defects. However, due to technological reasons pixel defects can occur.
This is not a malfunction; it is a part of the technical specifications.
DLT-V72 Operating Instructions V2.50 Preliminary
®
Intel ATOM™ E3845 Quad Core 1.91 GHz
Dual channel 1333 MHz memory bus speed
2 MB L2 cache, 22 nm
4 GB RAM
DDR3L Technology
AMI Aptio UEFI; ACPI 5.0 compliant
Real-time clock with a power reserve of up to 5 years
4 GB and more CFast memory card
Approx. 3.6 kg
Approx. 4.6 kg
Approx. 3.7 kg
Approx. 3.7 kg
Approx. 0.15 kg
Rugged aluminum-cast housing, ESD safe
10.4" XGA color TFT with 1024 x 768 resolution and 400 cd/m²
brightness
12.1" XGA color TFT with 1024 x 768 resolution and 500 cd/m²
brightness
10.1" widescreen WXGA color TFT display with 1280 x 800 resolution
and 500 cd/m² brightness
12.1" XGA color TFT with 1024 x 768 resolution and 600 cd/m²
brightness
