Step 1 - Plan Scanning System ........................................................... 1-2
Step 2 - Verify Read Range and Scan Width....................................... 1-3
Step 3 - Calculate Number of Scans.................................................... 1-4
Step 4 - Attach Cabling ........................................................................ 1-6
Step 5 - Configure Scanner ................................................................. 1-8
Step 6 - Position Scanner and Label ................................................... 1-9
Step 7 - Do Read Rate Test............................................................... 1-10
Step 8 - Adjust Other Scanning Parameters ...................................... 1-11
Step 9 - Install Scanner...................................................................... 1-13
Step 10 - Position Object Detector..................................................... 1-14
Operational Tips................................................................................. 1-15
Ground and Shield Considerations .................................................... 1-16
This chapter provides step-by-step instructions for setting up and installing
the MS-610 scanner.
Note: Bar code labels should meet minimum ANSI (American National Stan-
dards Institute) standards as specified in ANSI Bar Code Print Quality Guide-
line, X3.182-1990.
MS-610 Scanner User's Manual
Setup and
Installation
