Verify Read Range and Scan Width
Table 1-1 shows readable ranges and maximum scan widths for specific
bar code density (narrow-bar-width) types. Use this table as a reference to
verify that the planned range for your label falls within one of the listed
ranges.
Scan width is that portion of the scan line in which a label can be read. For
ladder oriented labels, scan width must only be wide enough to fully cover
the label length, including quiet zones. With picket fence oriented labels,
scan width is a factor in determining the time in which the label can be read
(see Calculate Number of Scans" on page 1-4).
Table 1-1 Read Ranges and Scan Widths
Laser
Range
Type
UHD
Visible
Standard
UHD
Infrared
Standard
a. Read range is the distance of the label from the scanner (measured from the front of the
scanner bezel) in which the label can be reliably read. The distance between the minimum
and maximum ranges is the depth of field.
For information on label orientation, see Appendix C, "Orientation," on page
A-6.
MS-610 Scanner User's Manual
Verify Read Range and Scan Width
Narrow-
a
Read Range
bar-width
.0047" 1.75–3" (45–76 mm)
.0075" 1–4" (25–102 mm)
.0075" 2–5" (51–127 mm)
.010" 1.5–6" (38–152 mm)
.015" 1–7" (25–178 mm)
.020" 1–9" (25–229 mm)
.030" 4–10" (102–254 mm)
.040" 4–10" (102–254 mm)
.050" 5–10" (127–254 mm)
.0047" 1.75–3" (45–76 mm)
.0075" 1.25–3" (32–76 mm)
.0075" 2–4.5" (51–114 mm)
.010" 1.5–5" (38–127 mm)
.015" 1–6" (25–152 mm)
.020" 1–7" (25–178 mm)
.030" 4–9" (102–229 mm)
.040" 4–9" (102–229 mm)
.050" 5–9" (127–229 mm)
Maximum Scan
Width
3" (76 mm)
4" (102 mm)
4.75" (121 mm)
6" (152 mm)
7.5" (191 mm)
9.25" (235 mm)
9.5" (241 mm)
9.5" (241 mm)
9.75" (248 mm)
3" (76 mm)
3.5" (89 mm)
3.5" (89 mm)
4.75" (1.21 mm)
6" (152 mm)
7" (178 mm)
8.5" (216 mm)
8.5" (216 mm)
8.5" (216 mm)
1-3
