Chapter 3 Serial Configuration

Summary of Serial Configuration Commands

Table 3-1 Summary of Serial Configuration Commands

Function Parameter
(Not in
menu)
Commun-
ications
Operations
Code Types
3-2
MS-610 Scanner User's Manual
Command
Trigger Filter
KF
Timing Value
Communications
Kf
Protocol
Kd Preamble
Ke Postamble
KA Response Timeout
Kc LRC
KB Intercharacter Delay
Ka Host Port
Kb RS-422
Kg Triggering Mode
Kh End of Read Cycle
Serial Trigger
Ki
Character
Kj External Trigger Level
Kk Noread Message
Kl Bar Code Output
Km Good Decode Reads
Kn Match Code
Ko Narrow Margins
Kp Code 39
Kq Codabar
Kr Interleaved 2 of 5
Ks UPC/EAN
Kt Code 128
Format
<KF?>
<KFtime in 10 ms incre-
ments>
<Kfprotocol,address>
<Kdstatus,ASCII characters>
<Kestatus,ASCII characters>
<KAtimeout setting>
<Kcstatus>
<KBnumber>
<Kabaud,parity,stop bits,data
bits>
<Kbstatus>
<Kgmode>
<Khmode,time>
<Kicharacter>
<Kjmode>
<Kkstatus,message>
<Klstatus,when to output>
<Kmnumber>
<Knstatus>
<Kostatus>
<Kpstatus,check digit status,
check digit output status,large
intercharacter gap,fixed code
length status,code length>
<Kqstatus,start & stop match
status,start & stop output sta-
tus,large intercharacter
gap,fixed code length sta-
tus,code length>
<Krstatus,check digit,check
digit
output,lengthþ1,length 2>
<Ksstatus,EAN status,sup-
plementals status,separator
status,
separator char.>
<Ktstatus,fixed length,length>
