Chapter 2 Menu Configuration
End of Read Cycle
Default: Timeout
Options: Timeout, New Trigger, Timeout & New Trigger
Allows you to choose the circumstances that will end the read cycle. The read
cycle is the time during which the scanner will receive and process label data.
When the Triggering Mode option is set in an External or Serial mode of opera-
tion, the trigger event initiates the read cycle.
Note: When operating in Continuous Read or Continuous Read 1 Output, the
scanner is always in the read cycle.
Selecting:
Timeout Can end the read cycle after a specified period of time, and if
no label has been read, causes a noread message, if enabled,
to be transmitted.
With either External Edge, Serial Data, or Serial Data & Edge
enabled, a timeout ends the read cycle.
With External Level enabled, the read cycle does not end until
the falling edge trigger occurs, and the next read cycle does
not begin until the next rising edge trigger.
With Continuous Read 1 Output enabled, a timeout initiates a
new read cycle and allows the same label to be read again.
New Trigger Ends the read cycle at the occurrence of a new trigger event,
and if no label has been read, causes a noread message, if
enabled, to be transmitted at the occurrence of the new trigger
event.
With either External Edge, Serial Data, or Serial Data & Edge
enabled, an edge or serial trigger ends a read cycle and
initiates the next read cycle.
With External Level enabled, a falling edge trigger ends a read
cycle. However, the next read cycle does not begin until the
occurrence of the next rising edge trigger.
Timeout & Ends the read cycle after a specified period of time or at the
New Trigger occurrence of new trigger event, and if no label has been read,
causes a noread message, if enabled, to be transmitted.
With either External Edge, Serial Data, or Serial Data & Edge
enabled, a timeout, or an edge or serial trigger, whichever
comes first, ends the read cycle.
With External Level enabled, the read cycle does not end until
the occurrence of a falling edge, and the next read cycle does
not begin until the next rising edge trigger.
