Table 3-1 Summary of Serial Configuration Commands (continued)
Function Parameter
Ku
KN
KC
User Kz
Outputs
Kv
Kw
Kx
KE

Serial Configuration Command Format

The format for a serial configuration command is,
<Kparameterdata,data,...etc.><initializing command>
Where:
• Less than < and greater than > symbols are included as part of the com-
1
mands.
• "parameter," as used here, are those character(s) that precede the data.
• The "initializing command" <A> or <Z> is sent after configuration is com-
plete. <Z> resets and saves for power up. <A> initializes the change to
2
RAM. (For more information, see page 4-3.)
For example, the following command enables UPC and saves the change
for power-on: <Ks1><Z>.
When using serial configuration commands, note also the following conven-
tions:
• Parameters and data are "case sensitive." That is, characters must be
entered as upper or lower case, as specified.
• All data fields (except the last) must be followed by a comma (without a
space).
• If there is no change in a given field, then commas can be entered alone,
or with the existing data (for example, <Ka,,,0> or <Ka4,1,0,0>).
1. Command start character by default is a left angle bracket, <. It may be redefined by menu or serial com-
mand. However, the end character, a right angle bracket, >, cannot be changed.
2. See "Initializing serial configuration commands" on page 3-4 for definitions and examples.
MS-610 Scanner User's Manual
Command
Beeper <Kustatus,volume,speed>
New Master Pin <KNstatus>
Laser On/Off <KCstatus>
Clock Speed <Kzspeed>
Relay Driver <Kvstatus>
Relay Polarity <Kwstatus>
Relay Pulse Width <Kxnumber>
Command Start Character <KEASCII character>
Format
3-3
