15. VEHICLE LIFTING PROCEDURES

To raise the vehicle, place the lifting equipment only at the points indicated. Failure to use these
precise positions may result in permanent vehicle body deformation.
Many dealer service facilities and service stations are equipped with automative hoists that
bear upon some parts of the frame in order to lift the vehicle. If any other hoist method is used,
take special care to avoid damaging the fuel tank, the filter neck, the exhaust system, or the
underbody.
1) Using Floor Jack
Front Side
2) Using Jack
Front Jack Up Point
ENGINE GENERAL
RODIUS 2004.09
Front Side
Rear Jack Up Point
