02-6
8410-05
3. ICM(INTERGRATED CONTROL MODULE) BOX
COMPARTMENT
The ICM box is installed along with RK STICS on the bracket behind the Instrument panel
undercover.
It contains an integrated module with around 14 relays according to the vehicle model.
Relays in the module are installed on the integrated circuit with a safety circuit.
This system operates with small current (by using transistor) and minimizes the sparks that
occur during operations (connection/disconnection) of relays; therefore its durability and wear
resistance has been greatly increased compared to the conventional relays.
Relays in the ICM box cannot be replaced respectively; so when the internal components
(including relay) are defective , ICM box should be replaced as an assembly.
FUSES
RODIUS 2004.09
RK STICS
ICM box
