When using a beam setting device
1.
Align the vehicle and beam setting device according to the operating instructions provided
by the manufacturer.
2.
Adjust the headlamp aiming by rotating the direction control levers (Up, Down, Left, Right) in
turn with a screwdriver.
Cautions During the Aiming
▶
Procedures
The headlamp angle should be within the
adjustment range as shown in the figure.
Adjust the headlamp aiming by rotating the
direction control levers (Up, Down, Left,
Right) in turn with a screwdriver.
05-11
8310-01
LAMP
RODIUS 2004.09
