Appendix A - Technical Specifications
Contactless Reader:
Acceptable Swipe Speeds:
Data Connections:
Wireless Range(s):
Battery Capacity:
Battery Charge, Powered Off:
Battery Charge, Active:
Power Inputs:
Maximum Current Draw:
Voltage Requirement:
Battery Type:
RF Frequencies and Power:
RF Exposure:
Flash Memory:
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Installation and Operation Manual
DynaPro Go Technical Specifications
EMVCo Contactless L1
D-PAS®, PayPass™/MCL, payWave®, ExpressPay®
Mobile wallets including but not limited to Apple Pay®, Google
Pay, Samsung Pay®
10 inches per second to 50 inches per second
Communications Characteristics
Micro-USB, implements USB 1.1 and USB 2.0
TCP/IP over 802.11 wireless (select models)
Bluetooth LE Secure Connections with Numeric Comparison
(select models)
Line of sight in office conditions:
802.11 wireless network: 150 ft. (45m) or greater
Bluetooth LE connection: 150 ft. (45m) or greater
NFC: 1.6 in. (40mm)
Electrical Characteristics
1700 mAh nominal (rated)
6 months minimum (new device)
5 hours / Over 100 transactions per charge
micro-USB connector
Charging cradle contacts
1A
5VDC
Lithium Polymer rechargeable for main power
Lithium coin cell for backup
802.11 Wireless Connection:
Average power radiated = 1.02 mW (0.08 dBm)
Conducted power = 97.7 mW (19.89 dBm)
Frequency range = 2400 MHz to 2497 MHz
Bluetooth LE connection:
Average power radiated = 2.4 mW (3.8 dBm)
Conducted power = 1.0 mW (0 dBm)
Frequency range = 2400 MHz to 2483 MHz
Contactless reader:
Radiated power: 10.34dBm
Frequency range: 13.553 MHz to 13.567MHz
Exempt from SAR requirements due to radiated power
substantially below regulatory thresholds.
256 MBit
Page 76 of 77 (D998200129-20)
