6 - Configuration

6.4.4 How to Configure the Device for 802.11 Wireless

To configure the device so a host can connect to it via 802.11 wireless, follow these steps:
1) Gather the SSID and passcode for the 802.11 wireless access point the device will connect to.
2) If the solution is using static IP addresses, gather the IP address, gateway, and subnet mask to use.
3) If the secure Windows workstation for advanced users has not already been set up, set it up as
follows:
a) Obtain a copy of 99510127 DYNAPRO/DYNAPRO GO/DYNAPRO MINI WINDOWS SDK
INSTALL (EXE) from MagTek and run the installer
b) In Windows Explorer, open the SDK installation location. By default:
i) On Windows 64-bit workstations, the default location is
(x86)\MagTek\PCI PED Windows SDK\Sample Code\DotNET Host Simulator
Demo\Object
ii) On Windows 32-bit workstations, the default location is
PED Windows SDK\Sample Code\DotNET Host simulator Demo\Object
c) For convenience, create a shortcut to
4) Make sure no other MagTek devices are connected to any of the host's USB ports.
5) Power on the device.
6) Make sure the device is in USB mode by checking the current Active Connection icon at the top of
the display. Use
Left Function Key 4 5 6 Right Function Key
7) Connect the device to the host's USB port (see section 5.3.1 How to Connect DynaPro Go to a Host
or Charger via USB). At the end, the device drivers are installed on the test workstation, and the
device is powered on, shows the USB icon at the top of the display (indicating the device Active
Connection is USB), and shows
8) Launch PCIPED_HASim.exe
9) Under Device Connection method
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Installation and Operation Manual
.
PCIPED_HASim.exe
on the display.
Welcome
to show a MagTek PCI PED Host App Simulator
, select USB
Page 37 of 77 (D998200129-20)
99510127-rev.exe
C:\Program Files
C:\Program Files\MagTek\PCI
on the desktop.
to change it if necessary.
.
.
.
window.
