Secure Card Reader Authenticator
MAGTEK RECOMMENDS
CHARGING EVERY 6 MONTHS TO
MAXIMIZE OPERATION.
STORAGE TEMPERATURE:
32°F TO 113°F (0°C TO 45°C)
kDynamo Overview
kDynamo makes mobile payments and card reading easier than ever and adds EMV contactless/
NFC and contact EMV chip card reading capabilities while maintaining its small footprint. There
are two models for kDynamo: kDynamo Air and kDynamo mini. kDynamo Air is Made for iPad
(4th, 5th, and 6th generation), iPad Pro (9.7 inch), iPad Air, and iPad Air 2. kDynamo mini is
Made for iPad mini (2, 3, and 4). See the Installation and Operation Manual for complete details.
Installation
Installing kDynamo is a straightforward process since the kDynamo uses user host controls.
kDynamo mini keeps you on the go with its smaller size and handheld ease-of-use. kDynamo Air
features a 100mm VESA (Video Electronics Standards Association) standard mounting pattern
that provides fixed mounting for greater security and convenience, allowing users to deploy
kDynamo Air in a variety of off the shelf semi-mobile or permanent mounts, and eliminating the
need for expensive customization.
Mounting options are further detailed in the complete Installation and Operation Manual.
kDynamo mini: Handheld with iPad mini (2, 3, and 4). Supports third-party adhesive-
•
mounted hand strap.
kDynamo Air with iPad (4th, 5th, and 6th generation), iPad Pro (9.7 inch), iPad Air, and iPad Air 2
•
Handheld
•
100mm VESA mount points for third-party stands or hand straps
•
kDynamo
Quick Installation Guide
www.magtek.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Magtek kDynamo Series
Summary of Contents for Magtek kDynamo Series
- Page 1 Secure Card Reader Authenticator Quick Installation Guide MAGTEK RECOMMENDS CHARGING EVERY 6 MONTHS TO MAXIMIZE OPERATION. STORAGE TEMPERATURE: 32°F TO 113°F (0°C TO 45°C) kDynamo Overview kDynamo makes mobile payments and card reading easier than ever and adds EMV contactless/ NFC and contact EMV chip card reading capabilities while maintaining its small footprint.
- Page 2 Major Components Overview kDynamo connects to an iPad host via the Lightning connector. An additional adapter shell, which is included with each device and which varies based on the iPad model being used, snaps on to kDynamo to secure and surround the host. Figure 1 - kDynamo Air Major Components Figure 2 - kDynamo mini Major Components...
- Page 3 On the host, install and configure the host software you intend to use with kDynamo. If you do not yet have host software, you can download a test tool from the App Store called MagTek Test, published by MagTek, Inc., to perform simple tests.
- Page 4 • Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by MagTek could void the user’s authority to operate this equipment. CE STANDARDS Testing for compliance with CE requirements was performed by an independent laboratory. The unit under test was found compliant with standards established for Class B devices.
