5 - Installation

5.3.3 How to Connect DynaPro Go to a Host via the Bluetooth LE Connection

To connect DynaPro Go to a host via the Bluetooth LE connection, follow these steps:
1) Make sure the host's hardware and operating system support Bluetooth LE Secure Connections,
which were introduced in the Bluetooth Core Specification version 4.2.
2) On the host, install and configure the software you intend to use with DynaPro Go.
3) Power on the device and make sure the battery is charged. Note that it is not always necessary to
explicitly turn on the device before using it; if the device is not powered on, it will start powering on
when a host establishes a connection.
4) Make sure the device's active connection is set to Bluetooth LE, using the steps in section 6.3 How to
Change the Active Connection.
5) Press
Left Function Key 1 2 3 Right Function Key
pairing requests for up to three minutes. The device indicates it is accepting pairing requests, and
displays the remaining time.
6) On the host, scan for Bluetooth devices, and select the device you want to pair to. On Windows and
Android hosts, use the operating system's Bluetooth setup features. On iOS hosts, you must use
custom host software designed specifically to pair with DynaPro Go (see section 9 Developing
Custom Software).
7) The device responds to the pairing request by showing a 6-digit passcode on the display, and the host
software should show a matching passcode. If the device does not show the passcode or the host fails
to pair, make sure the host's operating system and Bluetooth hardware support Bluetooth LE Secure
Connections, which were introduced in the Bluetooth Core Specification version 4.2.
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Installation and Operation Manual
Page 26 of 77 (D998200129-20)
to enable the device to accept Bluetooth LE
