Dimensions - Danfoss VLT 3000 Series Product Manual

IP 00
220 volt
®
VLT type 3002-3004
A (mm) 300
B (mm) 281
C (mm) 178
D (mm)
a (mm) 191
b (mm) 258
above/below (mm) 150
left/right (mm)
380 / 500 volt
VLT ® type 3002-04 With brake
A (mm) 300
B (mm) 281
C (mm) 178
D (mm) 55
a (mm) 191
b (mm) 258
above/below (mm) 150
left/right (mm) 0
IP 20
220 volt
VLT ® type 3006-3008
A (mm) 660
B (mm) 242
C (mm) 260
a (mm) 640
b (mm) 200
above/below (mm) 200
left/right (mm)
380 / 500 volt
®
VLT type 3011-3016
A (mm)
B (mm)
C (mm)
a (mm)
b (mm)
above/below (mm)
left/right (mm)
28

Dimensions

With brake
440
281
178
55 55
330
258
150
0 0
3006 With brake
440 440
281 281
178 178
55 55
330 330
258 258
150 150
0 0
3011 3016-3022
780
242
260
760
200
200
0 0
3022
660 780
242 242
260 260
640 760
200 200
200 200
0 0
®
MG.30.A7.02 - VLT is a registered Danfoss trademark
3008 With brake
550 500 610
281 281 281
178 178 178
55 55 55
440 330 440
258 258 258
150 150 150
0 0 0
950
308
296
930
270
200
0
3032-3052
950
308
296
930
270
200
0
RFI module
RFI-LC filter module
Options LC module
Clamp module
Brake module
A (mm) 115
B (mm) 281
C (mm) 178
D (mm) -
a (mm) 57.5
b (mm) 258
above/below (mm) 150
left/right (mm) 0
