Functions and timers,

Group 3..

Inputs and outputs

Group 4..
The analogue output signals on terminals 42/45 set in parameters 407/408.
Data 13/14
Data 15/16
Data 17/18
72
Group description
This group includes a parameter called
"flying start".
Function of the "flying start" when selected:
Example 1:
Group 4.. is used to program other
configurations of the terminals than the
default configuration.
See the configuration of the digital input
signals on page 32.
Data 19/20
Data 21/22
Data 23/24
®
MG.30.A7.02 - VLT is a registered Danfoss trademark
This function tells the frequency converter
how to handle a motor with a rotating
shaft.
Example 2:
: Flying start
: Normal start
: Dont care
The analogue output signals and the
relays can be used for different types of
indication.
See parameters 407 and 408.
Data 25/26
Data 0/12
Example 3: Example 4:
Condition fulfilled
(see page 108-109)
