Parameter description
406
Binary input 32/33
(Input 32/33)
(Continued)
108
= Factory setting. Text in ( ) = Display text.
The figures in [ ] are used in bus communication.
®
MG.30.A7.02 - VLT is a registered Danfoss trademark
4.. Inputs and outputs
4 setup extended: Selected if the same
function is required on terminals 32/33 as
on the first generation of VLT
with extended control card and 4 setup
functions. If freeze reference is not se-
lected in parameters 400, 401 and 405, the
setups are follows:
Setup Terminal 32
1 0
2 0
3 1
4 1
If, on the other hand, freeze reference is
selected in either parameter 400, 401 or
405, selection can be made between two
functions using terminal 16, 17 or 29.
Terminal 16, 17 or 29 = "0".
Setup Terminal 32
1 0
2 0
3 1
4 1
Terminal 16, 17 or 29 = "1".
Terminal 32
Freeze reference (sum) 0
Increase reference 0
Reduce reference 1
Reduce reference 1
® 3000 Series
Terminal 33
0
1
0
1
Terminal 33
0
1
0
1
Terminal 33
0
1
0
1
