Menu build-up

Parameter
numbering
Travelling through
the menu
Data value of a
parameter
Changing a data value:
digit
Changing a data value:
text
Leaving DATA mode
Menu build-up
The frequency converter has a menu sys-
tem with several parameters to be used to
optimise your motor operation.
The parameters are divided into 7 groups
(group 0 - group 6).
There are also groups for different options.
They are described in guidelines for each
option.
The parameter number is made up of three
digits.
The digit on the left indicates the group.
After the first power-up you will find the
frequency converter in DISPLAY MODE.
Changing group
If you want to travel through the menu, use
the key followed by the keys
Menu
(see page 61).
When you have chosen a parameter and
want to change its data value, press the
key followed by the
+
Data
When you have pressed
right will be active and be shown flashing.
The other digits can be activated one by
one by pressing one, two or three times.
Data
The activated digit can be changed by
pressing or .
+ –
If the data value of the chosen parameter
is a text, the display shows the selected
text.This can be changed by pressing
and then or . All options are then
+
–
shown one by one. The text shown in the
display will be stored at the same moment
you leave DATA MODE.
You are storing the data value by pressing
. Now you have activated the para-
Menu
meter number and can travel through the
group of parameters again using
®
MG.30.A7.02 - VLT is a registered Danfoss trademark
Parameter grouping
0..
1..
2..
3..
4..
5..
6..
Within each group the parameters are
numbered, starting with 0.
For example, in group 1..: 100, 101, 102....
Changing a parameter number
You can enter the parameters of the
selected group with the key
by
+
or increases and
+ +
–
parameter number.
The data value can be a digit or a text.
or key.
–
A new data value is stored on leaving
the digit to the
Data
DATA MODE, or automatically after 20
seconds.
Please note: You have to press
the motor before changing the data values
of some parameters (see factory settings).
Please note: You have to press
the motor before changing the data values
of some parameters (see factory settings).
Data
and .
+ –
Operation and display
Load and motor
References and limits
Functions and timers
Inputs and outputs
Serial data interface
Service and diagnosis
followed
Menu
or .
–
decreases the
–
000-099
100-199
200-299
300-399
400-499
500-599
600-699
to stop
Stop
Reset
to stop
Stop
Reset
