Operating Guide | VLT® AQUA Drive FC 202

3 Product Overview

3.1 Intended Use

OUTPUT FREQUENCY LIMIT
Due to export control regulations, the output frequency of the drive is limited to 590 Hz. For demands exceeding 590 Hz,
contact Danfoss.
The drive is an electronic motor controller that converts AC mains input into a variable AC waveform output. The frequency and
voltage of the output are regulated to control the motor speed or torque. The drive is designed to:
• Regulate motor speed in response to system feedback or remote commands from external controllers.
• Monitor system and motor status.
• Provide motor overload protection.
Depending on the configuration, the drive can be used in standalone applications or form part of a larger system or installation.
The drive is allowed for use in industrial and commercial environments in accordance with local laws and standards. Do not use the
drive in applications which are non-compliant with specified operating conditions and environments.
3.2 Power Ratings, Weights, and Dimensions for E1h–E4h Enclosures
Table 2: Power Ratings, Weights, and Dimensions for E1h–E4h Enclosures (Standard Configurations)
Enclosure size
Rated power at 380–480 V [kW
(hp)]
Rated power at 525–690 V [kW
(hp)]
Enclosure protection rating
Unit dimensions
Height [mm (in)]
Width [mm (in)]
Depth [mm (in)]
Weight [kg (lb)]
Shipping dimensions
Height [mm (in)]
Width [mm (in)]
Depth [mm (in)]
Weight [kg (lb)]
1
Type 1 and Type 12 are UL designations.
12 | Danfoss A/S © 2020.01
E1h
355–450 (500–600)
450–6300 (450–650)
IP21/Type 1 IP54/
(1)
Type 12
2043 (80.4)
602 (23.7)
513 (20.2)
295 (650)
2191 (86.3)
768 (30.2)
870 (34.3)
–
N O T I C E
E2h
500–560 (650–750)
710–800 (750–950)
IP21/Type 1 IP54/
Type 12
2043 (80.4)
698 (27.5)
513 (20.2)
318 (700)
2191 (86.3)
768 (30.2)
870 (34.3)
–
Product Overview
E3h
355–450 (500–600) 500–560 (650–750)
450–630 (450–650) 710–800 (750–950)
IP20/Chassis IP20/Chassis
1578 (62.1) 1578 (62.1)
506 (19.9) 604 (23.89)
482 (19.0) 482 (19.0)
272 (600) 295 (650)
1759 (69.3) 1759 (69.3)
746 (29.4) 746 (29.4)
794 (31.3) 794 (31.3)
–
AQ275652274277en-000101 / 130R0708
E4h
–
