Parameter description
311
Trip delay at inverter
fault
(Trip dly@fault)
312
Max. auto restart time
(Auto restart t)
313
Motor check
(Motor check)
314
Motor pre-heat
(Motor pre-heat)
315
Motor thermal
protection
(Motor thermal)
316
Relay ON-delay
(Relay on delay)
317
Relay OFF-delay
(Relay off dela)
100
Value:
0 - 35 sec.
Software version 3.11:
Under voltage fixed
Over voltage
Value:
0 - 10 sec. 5 sec.
Value:
Off (OFF)
On (ON)
Value:
Off (OFF)
On (ON)
Value:
Off (OFF)
Warning 1 (warning 1)
Trip 1 (trip 1)
Warning 2 (warning 2)
Trip 2 (trip 2)
Warning 3 (warning 3)
Trip 3 (trip 3)
Warning 4 (warning 4)
Trip 4 (trip 4)
Value:
0.00 - 10.00 sec.
Value:
0.00 - 10.00 sec.
= Factory setting. Text in ( ) = Display text.
The figures in [ ] are used in bus communication.
®
MG.30.A7.02 - VLT is a registered Danfoss trademark
When the frequency converter registers an
Depending over- or under-voltage in the inverter it will
on unit await a final trip. Record for how long you
want the frequency converter to wait
beforetripping out.
25 sec.
Note: If this value is reduced from the
0 sec.
factory setting, the unit may report a fault
at Power on (undervoltage).
Sets the max. time allowed for auto restart
before a final trip, if selected in para. 309.
If "on" is selected the presence of a motor
is checked when there is 24 V voltage to
[0]
[1] terminal 27 and no start command has
been given (START, START REV. or
JOG). If a motor is not connected, the mes-
sage NO MOTOR is shown. This function
is not found for VLT
V, and VLT
If "on" is selected the motor will be pre-
heated by a DC current when motor
[0]
coasting is permitted (terminal 27 = on)
[1]
and no start command has been given
(START, START REV. or JOG). This func-
tion is not found for VLT
230 V, and VLT
The frequency converter calculates
whether the motor temperature exceeds
[0]
[1] the permissible limits. The calculation is
based on 1.16 x rated motor current (set
[2]
[3] in parameter 107). Four separate calcula-
tions are possible, so that one can be
[4]
chosen for each setup or the same
[5]
calculation can be used in several
[6]
setups. Select off if you do not want
[7]
either warning or trip.
[8]
Select warning only if you want a warning
in the display when the motor is overheating.
You can also program the frequency con-
verter to give a warning signal via the
signal outputs (parameters 407-410).
Select "trip" if trip is required when the motor
is overloaded.
You can also program the frequency con-
verter to give a alarm signal via the signal
outputs (parameters 407-410). See graph
on page 130.
The delay timers will influence the switch
in/out delay of the relay associated with ter-
0.00
minals 01-02-03.
0.00
3.. Functions and timers
types 3032-3052, 230
®
types 3060-3250.
®
types 3032-3052,
®
types 3060-3250.
®
