Vlt®3032-3052, 230 V, Vlt 3060-3250; Cable Access - Danfoss VLT 3000 Series Product Manual

VLT ® 3032-3052, 230 V,
®
VLT 3060-3250

Cable access:

42
Mechanical installation
The front door to VLT ® 3032-3052, 230 V,
®
and VLT 3060-3250 has hinges on the
left-hand side.
The table below shows the door radius
and the distance necessary from the
installation surface to be able to open the
door without difficulty.
VLT-type 3032-52, 230 V, 3100
3060 3075
C [mm] 846 846
R [mm] 505 505
VLT ® types 3002-3008, 400/500 V, and
VLT ® 3002-3004, 200 V, with IP 54 en-
closure have a plastic base with holes
marked for cable unions.
Note that for the above VLT
and 500 V (UL-approved) a metallic
bonding plate is included in the plastic
base. The metal plate is used to terminate
cable conductor or armouring. See the
information on p. 148 concerning connec-
tion of the bonding plate when IP 00 VLT
are converted to IP 21 enclosure with UL
approval.
The cable unions mechanically support the
cables for IP 21/54 enclosure. For the
IP 00 version, the cables must be relieved
by other means (cable stirrups). The
cables end in removable plugs.
®
VLT 3011-3052, 400/500 V, and VLT
3006-3022, 200 V, have a metal base with
cut-outs for cable lead-through.
®
The bottom of the VLT types 3032-3052,
230 V, and VLT ® types 3060-3250 has a
plate mounted with 6 cross-head screws.
The plate can be removed to ease installa-
tion of the cable unions. After cable lead-
through has been completed, the plate
must be screwed back in place to ensure
correct IP enclosure grade and cooling.
®
MG.30.A7.02 - VLT is a registered Danfoss trademark
3125 3150 3200
894 894 894 1008
513 513 513 513
It is recommended that the cables be lead
through the base, but the sides can also
be used.
The plate in the right-hand side of the
® ®
s for 200 V VLT enclosure can be removed, and the
hole can be used for cable lead-through if
an extra enclosure or an IP 54 RFI module
is required. If one of these modules is to
be used, the right-hand side of the VLT
enclosure may not be bored for other
®
s cables.
The VLT
avoid metal flakes flying into the VLT
electronics, cable holes should not be
bored until the unit has been vertically
installed.
The drawing below shows the VLT
3060-3250 seen from the bottom with the
®
removable base plate.
3250
1008
513
® enclosure is made of steel. To
®
® 's
®
types
