DISPLAY MODE
MENU MODE
PARAMETER MODE
DATA MODE
ALARM MODE

Display layout

The display will give you different infor-
mation, depending on the mode and the
operation setting.
SELECTED DISPLAY READ-OUT, including unit
NAME OF SELECTED DISPLAY READ-OUT
STATUS, including indication of local operation
FLASHING PARAMETER NUMBER
0.. = FLASHING CURSOR
FLASHING PARAMETER NUMBER
0.. = FLASHING CURSOR
SET DATA VALUE
E = FLASHING CURSOR
REASON FOR ALARM
®
MG.30.A7.02 - VLT is a registered Danfoss trademark
See the list of status, reset and alarm mes-
sages on page 122.
See the list of parameters on pages
151-152.
00.0 Hz
FREQUENCY
FUNCTION OK
00.0 Hz
0.. OPERATING
SETTING
00.0 Hz
00 0 LANGUAGE
ENGLISH
00.0 Hz
LANGUAGE
E NGLISH
SET DATA VALUE
ALARM
RESET MODE
TRIPPED
OVERVOLTAGE
ROTATION DIRECTION
1
ACTIVE SETUP
SELECTION
(1-4 CAN BE SELECTED
IN PARAMETER 001)
PARAMETER GROUP
NAME
PARAMETER NAME
1
PARAMETER NAME
1
61
