Mechanical installation
The drawing shows the base and its
dimensions.
VLT ® type
A [mm]
B [mm]
C [mm]
D [mm]
b [mm]
c [mm]
®
The bases for VLT and options have been
®
updated to match VLT 3100-3250 with
the removable plate in the bottom. Note
that the ventilation slots have been re-
placed with two apertures in the sides.
When a base is also used for the mounting
console and RFI in IP 54 enclosure,
remember to match up the ventilation
apertures.
The new base design can be used with
Base:
®
VLT type
A [mm]
B [mm]
a [mm]
b [mm]
Base for mounting console and IP 54, RFI module:
®
VLT type
A [mm]
B [mm]
a [mm]
b [mm]
®
MG.30.A7.02 - VLT is a registered Danfoss trademark
3100-3150
127
495
361
4 x 12.7
445
310
previous versions of VLT
units, but never use the previous base
design for the VLT ®
able base plate.
Base seen from side:
3100-3150
76
151
23
191
3100-3150
79
153
23
191
3200-3250
127
495
495
4 x 12.7
445
445
®
3100-3250
units with the remov-
3200-3250
100
176
10
287
3200-3250
102
178
10
287
