Mechanical dimensions

The drawings below describe the mechanical dimen-
sions. All dimensions are given in mm.
NOTE
Please note that all filter options must be
vertically mounted.
VLT 2803-2815 200-240 Volt
VLT 2805-2815 380-480 Volt
The drawing below gives the mechanical dimensions
of VLT 2822 (3 HP) 200-240 Volts and VLT 2822-2840
(3 - 5 HP) 380-480 Volts. All dimensions are in inches.
VLT 2822 200-240 Volt
VLT 2822-2840 380-480 Volt
6
®
VLT
2800 Series
VLT 2822 220 - 240 V, PD2
VLT 2840 200 - 240 Volt
VLT 2855-2875 380 - 480 Volt
VLT 2840 220 - 240 V, PD2
VLT 2880-82 380 - 480 V
®
MG.27.A2.22 - VLT
is a registered Danfoss trademark
