Specifications

5.2 Dimensions

5.2.1 90 kW Enclosure

A Front view
D Bottom view
Illustration 5.1 Front, Side Dimensions, Door Clearance, and Center of Gravity for 90 kW Enclosure
MG13B102
Installation Guide
A
C
800 mm
31.5 in
D
32.25 mm (1.27 in)
46.5 mm (1.83 in)
686.5 mm (27.03 in)
B Side view
E Top view
Danfoss A/S © 09/2015 All rights reserved.
B
C
605 mm
23.8 in
E
C Center of gravity
5 5
