8
SET MODE
Function (Continued)
» SET > Function
MENU
AFC Limit
Select whether to limit the operating range of the AFC
(Automatic Frequency Control) function, or not.
• OFF: Turns OFF the function.
• ON: Limits the operating range of the AFC function.
The limit value differs depending on the IF
filter width as described below.
IF Filter width
15 kHz
10 kHz
7 kHz
[NOTCH] Switch (SSB)
[NOTCH] Switch (AM)
Selects the notch function used in the SSB or AM mode.
• Auto: Only the Auto Notch function can be
used.
• Manual: Only the Manual Notch function can
be used.
• Auto/Manual: Both the Auto and Manual Notch
functions can be used.
SSB/CW Synchronous Tuning
Turns the Displayed Frequency Shift function ON or OFF.
This function automatically shifts the frequency to
match the CW pitch when the operating mode is
toggled between SSB and CW.
• OFF: Turns OFF the function.
• ON: When the operating mode is changed
between SSB and CW, the operating
frequency shifts by the offset amount.
CW Normal Side
Selects the carrier point in the CW normal mode.
• LSB: Sets the carrier point to the LSB side.
• USB: Sets the carrier point to the USB side.
Keyboard Type
Sets the keyboard entry type to Ten-Key or Full
Keyboard.
Full Keyboard Layout
Selects the on-screen keyboard layout between
English, German and French.
(Default: ON)
AFC limit value
±10 kHz
±7 kHz
±5 kHz
(Default: Auto/Manual)
(Default: Auto/Manual)
(Default: OFF)
(Default: USB)
(Default: Full Keyboard)
(Default: English)
Screen Capture [POWER] Switch
Assigns the Screen Capture function to
• OFF: does not act as the Screen Capture
POWER
key.
• ON: acts as the Screen Capture key.
POWER
Screen Capture File Type
Sets the file format for the Screen Capture function to
PNG or BMP.
» SET > Function > REF Adjust
MENU
REF Adjust
Adjusts the internal reference frequency.
REF Adjust (FINE)
Fine tune the value set in "REF Adjust."
NOTE: The default setting of "REF Adjust" may differ
slightly, depending on the transceiver's version.

My Station

» SET > My Station
MENU
My Call Sign (DV)
The transceiver has a total of 6 memories to save
your own call signs for DV mode.
You can enter a call sign of up to 8 digits. Also, a note
of up to 4 characters, for operating transceiver type,
area, and so on, can be entered.
TX Message (DV)
The transceiver has a total of 5 memories to save
short messages for simultaneous transmission in the
DV mode.
Enter a message of up to 20 alphanumeric characters
for each memory.
LTo transmit no message, select "OFF."
My Call Sign (DD)
The transceiver has a total of 6 memories to save
your own call signs for DD mode.
You can enter a call sign of up to 8 digits. Also, a note
of up to 4 characters, for operating transceiver type,
area, and so on, can be entered.
8-5
(Default: OFF)
.
POWER
(Default: PNG)
