3
BASIC OPERATION
Setting the frequency
D Entering a Band Edge (Continued)
Inserting a Band Edge
After you delete or edit the preset band edges, follow
the steps below to insert a band edge.
1. On the FUNCTION set screen, select "User Band
Edge."
2. Touch the band edge you want to insert a new
band edge above for 1 second.
(Example: 3: 1261.000.000–1300.000.000 MHz)
L The new band edge will be inserted above the
selected band edge.
3. Touch "Insert."
4. Enter the lower band edge frequency then touch
[ENT]. (Example: 430.1)
Entry example: [4] [3] [0]
5. Enter the upper band edge frequency, then touch
[ENT]. (Example: 439.9)
Entry example: 4 [3] [9]
[ ]
• The entered band edge is saved and returns to the
previous screen.
• [1] [ENT]
[ ]
• 9 [ENT]
[ ] [ ]
Resetting all band edges to presets
The steps below will reset all the band edges to their
initial settings. All entered settings will be deleted.
1. Open the "User Band Edge" screen.
2. Touch any band edge for 1 second.
3. Touch "Default."
"User Band Edge" screen
• Displays "Reset All Edges?"
4. Touch [YES].
• All the band edges reset to the initial settings.
3-9
