Icom IC-9700 Basic Manual page 15

D Multi-function menus
Touch the edge to
turn ON or OFF
Multi-function menu
z Open the Multi-function menu by pushing
(Multi-function control).
z Open special menus by holding down
, , or for 1 second.
NB NOTCH
NR
z While the Multi-function menu is open, touch the
desired item and rotate
value.
Multi-function menu items
* 1 Touch the edge to turn the function ON or OFF, or
when you want to adjust.
* 2 Touch the item for 1 second to enable
SSB SSB-D
* 2 * 2
RF POWER RF POWER
* 2 * 2
MIC GAIN MIC GAIN
* 1, * 2
COMP
* 1, * 2 * 1, *
MONITOR MONITOR
FM/AM/DV DD
* 2 * 2
RF POWER RF POWER
* 2 * 1
MIC GAIN TX INHIBIT
* 1, * 2
MONITOR
NOTCH VOX
* 2 * 2
POSITION GAIN
* 1 * 2
WIDTH ANTI VOX
* 2
DELAY
*
VOICE DELAY
Rotate
Push
MULTI
,
VOX/BK-IN
to set the desired
MULTI
.
MULTI
CW RTTY
* 2
RF POWER RF POWER
* 2 * 1
KEY SPEED TPF
* 2
CW PITCH
2 * 1,
MONITOR
NB NR
* 2 * 2
LEVEL LEVEL
* 2
DEPTH
* 2
WIDTH
BK-IN TX PWR LIMIT
* 2
DELAY RF POWER
LIMIT
1
Multi-function dial
When the Multi-function menu is closed,
be enabled to adjust functions that are either on the
upper right three keys or in the Multi-function menus.
The function is displayed in the upper right edge of the
screen.
* 1 You can independently enable
function for the MAIN and SUB bands.
* 2 On the Multi-function menus, touch the item for
1 second to assign the function to
Indicator
Rotate
* 1
RIT
Hold down Clears the RIT frequency.
Changes the operating frequency on the kHz
* 1
kHz
steps.
Selects Memory channels.
* 1
Using the DR function, selects an individual
M-CH
station or preset repeater.
* 2
Rotate
* 1
PBT1
Hold down Clears the Twin PBT setting.
Rotate
* 2
* 1
PBT2
Hold down Clears the Twin PBT setting.
* 2
RF PWR Adjusts the transmit output power.
* 2
Adjusts the microphone gain.
MIC G
* 2
Adjusts the Speech Compressor level.
COMP
* 2
MONI Adjusts the audio level for the Monitor function.
* 2 Sets the Key speed.
SPEED
* 2
Sets the CW pitch.
PITCH
* 2
* 2
Adjusts the Noise Blanker level.
NB LEV
* 2
NB DEP Adjusts the DEPTH (Noise attenuation level).
* 2 Adjusts the WIDTH (Blanking duration time).
NB WID
* 2
Adjusts the transmit output power.
NR LEV
* 2
Adjusts the Notch frequency.
NOTCH
* 2
VOX G Adjusts the VOX gain.
* 2 Adjusts the ANTI VOX level.
A-VOX
* 2
Adjusts the VOX delay time.
VOX D
* 2
Adjusts the Break-in delay time.
BKIN D
1-7
