Display modes
The LCP control unit has different display modes,
which depend on the mode selected for the
variable frequency drive.
Display mode I:
This display mode is standard after startup
or initialization.
FREQUENCY
50.0 Hz
MOTOR IS RUNNING
Line 2 shows the data value of an operating data
item with unit, and line 1 contains a text that explains
line 2. In the example, Frequency has been selected
as readout via parameter 009 Large display readout.
In normal operation, another variable can be entered
immediately using the [+ / -] keys.
Display mode II:
Switch between Display modes I and II is performed
by briefly pressing the [DISPLAY / STATUS] key.
24.3% 30.2% 13.8A
50.0 Hz
MOTOR IS RUNNING
In this mode, all data values for four operating
data items with any pertaining units are shown,
see table. In the example, the following have been
selected: Frequency, Reference, Torque and Current
as readout in the first and second line.
Display mode III:
This display mode is called up as long as the [DISPLAY
/ STATUS] key is held down. When the key is released
it switches back to Display mode II, unless the key is
held down for less than approx. 1 sec., in which case
the system always reverts to Display mode I.
REF% TORQUE CURR A
50.0 Hz
MOTOR IS RUNNING
96
SETUP
1
Decentral Solutions
Here you can read out the parameter names and
units for operating data in the first and second lines.
Line 2 in the display remains unchanged.
MG.90.F2.22 - VLT is a registered Danfoss trademark
