Description of choice:
The output current's upper signal limit I
programmed within the variable frequency drive's
normal operating range. See drawing at parameter
223 Warning: Low current, I
225 Warning: Low frequency, f
(WARN.FREQ. LOW)
Value:
0.0 - par. 226
Warn.: High frequency, f
Function:
If the output frequency falls below the preset
limit f
, a warning is given.
LOW
Parameters 223-228 Warning functions are out of
function during ramp-up after a start command and
after stop command or during stop. The warning
functions are activated when the output frequency
has reached the resulting reference. The signal
outputs can be programmed to give a warning signal
via terminal 46 and via the relay output.
Description of choice:
The lower signal limit of the output frequency f
must be programmed within the normal operating
range of the variable frequency drive. See drawing
at parameter 223 Warning: Low current, I
226 Warning: High frequency f
(WARN.FREQ.HIGH)
Value:
Par. 200 Frequency range = 0-132 Hz [0]/[1].
par. 225 f
- 132 Hz
LOW
Par. 200 Frequency range = 0-1000 Hz [2]/[3].
par. 225 f
- 1000 Hz
LOW
Function:
If the output frequency exceeds the preset limit
f
a warning is given.
HIGH
Parameters 223-228 Warning functions do not
work during ramp-up after a start command and
after stop command or during stop. The warning
functions are activated when the output frequency
has reached the resulting reference. The signal
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.90.F2.22 - VLT is a registered Danfoss trademark
must be
HIGH
.
LOW
LOW
0.0 Hz
HIGH
LOW
.
LOW
HIGH
132.0 Hz
132.0 Hz
Decentral Solutions
outputs can be programmed to give a warning signal
via terminal 46 and via the relay output.
Description of choice:
The output frequency's upper signal limit f
be programmed within the variable frequency drive's
normal operating range. See drawing at parameter
223 Warning: Low current, I
227 Warning: Low feedback, FB
(WARN.FEEDB. LOW)
Value:
-100,000.000 - par. 228 Warn.: FB
Function:
If the feedback signal falls below the preset limit
FB
, a warning is given.
LOW
Parameters 223-228 Warning functions are out of
function during ramp-up after a start command and
after a stop command or during stop. The warning
functions are activated when the output frequency has
reached the resulting reference.The signal outputs can
be programmed to give a warning signal via terminal 46
and via the relay output.The unit for feedback in Closed
loop is programmed in parameter 416 Process units.
Description of choice:
Set the required value within the feedback range
(parameter 414 Minimum feedback, FB
415 Maximum feedback, FB
228 Warning: High feedback, FB
(WARN.FEEDB HIGH)
Value:
Par. 227 Warn.: FB
LOW
Function:
If the feedback signal gets above the preset
limit FB
, a warning is given.
HIGH
Parameters 223-228 Warning functions are out of
function during ramp-up after a start command and
after a stop command or during stop. The warning
functions are activated when the output frequency has
reached the resulting reference. The signal outputs can
be programmed to give a warning signal via terminal 46
and via the relay output. The unit for feedback in Closed
loop is programmed in parameter 416 Process units.
must
HIGH
.
LOW
LOW
-4000.000
HIGH
and
MIN
).
MAX
HIGH
- 100,000.000
4000.000
125
