The installation box can be mounted with or without
a sealed connector (IP66) to connect the common
display LCP2 (code DC). The connector can be ordered
separately (Not for single sided installation boxes).
LCP2 keyboard/Display 175N0131 (for
the FCD 300 series)
Alphanumeric display for programming the
adjustable frequency drive.
Cable for LCP2 175N0162 (for the FCD 300 series)
Preconfectioned cable to be used between adjustable
frequency drive and LCP2.
Data cable for PC communication 175N2491
(for the FCD 300 series)
connects a drive (e.g. USB) to the LCP2 connector.
Remote mounting kit for LCP2 175N0160
(for the FCD 300 series)
Kit for permanent mounting of the LCP2 in an enclosure.
Venting membrane 175N2116
Membrane preventing water build-up due to
condensation inside enclosures.
Star point terminal 175N2119
Six wires must be either star- or delta-connected to
supply an AC motor. Delta connection is possible
in the standard motor terminal. Star connection
requires a separate terminal.
5 pole M12 plug for e.g. DeviceNet 175N2279
(for the FCD 300 series)
The plug, micro type, M12 can be mounted into the
gland holes of the installation box. The plug can also be
used for other purposes such as connection of sensors.
6.5ft (2m) drop cable for DeviceNet 195N3113
(for the FCD 300 series)
The cable can be mounted inside the terminal
box, and connects to the DeviceNet trunk line
via a micro connector (M12).
Type
Internal brake resistor
Internal brake resistor
30
Description
FCD 303-307 Brake resistor for mounting inside the terminal
box
FCD 311-335 Brake resistor for mounting inside the terminal
box
Decentral Solutions
5 pole M12 plug for AS-interface 175N2281
The plug, M12, can be mounted into the gland
holes of the installation box.
Viton Gasket for FCD 303-315 175N2431
With this gasket the FCD can be used in painting
shops in e.g. the automotive industry.
Viton Gasket for FCD 322-335 175N2450
With this gasket the FCD can be used in painting
shops in e.g. the automotive industry.
Ordering numbers for brake resistors
Internally mountable brake resistors for low duty cycle
braking (1-3%). The resistors are self-protecting.
Internal brake resistors cannot be mounted in
FCD 303-315 with service switch.
MG.90.F2.22 - VLT is a registered Danfoss trademark
Ordering no.
175N2154
175N2117
