Summary of Contents for Danfoss VLT DMS 300

  • Page 1: Table Of Contents

    Galvonic isolation (PELV) ..................47 Electrical Schematic ....................48 Setting up DMS 300 ..................49 Adjustment/ Settings ....................49 Start/ stop profile setting ..................49 Start/ stop profile setting table: ................50 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 2 Mechanical Installation ................... 70 General information about electrical installation ............. 73 Electronics purchased without installation box ............73 EMC-correct electrical installation ................75 Grounding of shielded/armoured control cables ............. 77 Diagram ......................... 78 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 3 All About FCD 300 ..................173 Dynamic braking ....................173 Internal Brake Resistor ..................177 Special conditions ....................179 Galvonic isolation (PELV) ..................179 Ground leakage current and RCD relays ............... 180 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 4 General technical data ..................194 Technical data, line supply 3 x 380 - 480V ............199 Available literature ....................200 Supplied with the unit ................... 200 Factory Settings ....................201 Index ........................209 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 5: The Decentral Concept

    Decentral Solutions Introduction concept and guide you through the process of Danfoss was the world’s first company to manufacture selecting the appropriate products. and supply variable frequency drives for infinitely variable Finally we have included comprehensive information speed control of three-phase AC motors. Until then, about the Danfoss decentralized products.
  • Page 6: Decentral Design Benefits

    Commissioning is easier and faster Decentralized motor control is rapidly gaining ground despite of the advantages of the centralized control concept: • no need for extra space around the motor or close to the motor MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 7 L between each drive and the distance h between each row and also with a distance h from the centralized power entry/cabinet location to the first row. There are n rows, and N drives in each row. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 8 I/O-stations, Real case the extension will be limited. Decentralized products from Danfoss can even be used as remote I/O Calculations on a specific, typical bottling line with 91 pieces of 1.5 HP (1.5 kW) motors, taking the cable...
  • Page 9 Modularization can minimize lead-time. Even manufacturers of large production equipment The process of rebuilding the application at the or lines use modularization to reduce lead-time. production site is considerably simplified by shipping MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 10 FCD 300. Combining Danfoss adjustable frequency inverter. As the rectifier itself produces a rippled DC drives to Danfoss geared motors makes it even voltage, a capacitor is often introduced to smooth easier as they fit mechanically and the motor data are the voltage supplied to the inverter.
  • Page 11 Principle of a adjustable frequency drive using a DC link coil The Danfoss option is to add coils to the DC link in all drives as shown in the figure. This way a high DC link voltage with a very low voltage ripple is obtained and the electric strength of the drive with regard to line transients is improved.
  • Page 12 Decentral Solutions material is offered by Danfoss to eliminate this problem. The cable gland should be used in applications Electrical contact can cause galvanic corrosion under exposed to frequent temperature fluctuations and wet or humid conditions. This can occur between humid environments as in equipment used only during housing (Aluminium) and screws (stainless steel).
  • Page 13: Application Examples

    In the following we provide illustrative examples of actual installations using Danfoss decentralized Danfoss has completed a wide range of applications products, and the benefit and value these provide in many different industries. This has given us a for the customer in these installations.
  • Page 14 Decentral Solutions • All in one box: e.g. service switch, Profibus and power looping MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 15 Same flexibility as with centrally mounted motor controls. Decentralized motor controls can be adapted for all standard AC motors, and feature same user interface and same numbers on connectors • Profibus integrated MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 16 No need for switchboard • Visible LED for status • Service switch integrated in the unit • High enclosure rating IP66 • Low cost installation • Less space needed for the new solution MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 17 Decentral Solutions Food conveyor Efficient space utilisation in the food industry with decentralized motor controls from Danfoss Benefits: • Dirt-repelling surface and design prevents dirt and product remains on the drive • The number of drives in an application can be •...
  • Page 18 Decentral Solutions standard AC motors, features same user interface and same numbering on connectors • Profibus integrated • Connectors for fast service integrated in the installation box MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 19 Low installation and component costs • No additional and expensive EMC connectors needed • Compact and space saving • Easy to install and commission • Input for motor thermistor monitoring Decentral installation in the automotive industry MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 20 • No expensive wiring: All motors use existing power cables, pipes and local switches • All motor controls can be controlled from the existing centralized cabinet via Profibus MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 21: Product Design Guide

    • Free choice of motor brand • Easy retrofitting to existing motor • Easy interfacing to motor (short cable) • Easy access for diagnosis and optimal serviceability MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 22 See also the section entitled Brake resistors for ordering a brake resistor. EB version including mechanical brake control/supply. Desired features are selected by specifying the corresponding fields in the string (xx). The choices - MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 23 DESINA standard (see electrical installation). Display connector for external pluggable connection of the local control panel for operating and programming. Can also be used for PC connection. Only available for FCD 300. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 24 * contact Danfoss sales org for availability Basic functions Electronic start/stop of a motor Soft start/stop Extended functionality Reverse for bi-directional operation of the motor Brake control and supply of electromechanical brake Current monitoring for electronic motor protection MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 25: Ordering Form - Dms 300

    Decentral Solutions Ordering form - DMS 300 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 26 Electronic motor protection and reverse are always included Extended functionality 24 V external back up of control and communication Brake control and supply of electromechanical brake Dynamic braking (brake resistor is optional see brake resistors) MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 27 • F00 - No fieldbus option built in • F10 - Profibus DP V0/V1 3 Mbaud • F12 - Profibus DP V0/V1 12 Mbaud • F30 - DeviceNet • F70 - AS-interface MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 28: Ordering Form - Fcd 300

    Decentral Solutions Ordering form - FCD 300 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 29: Pc Software Tools

    LOP can be used for setting the reference 175N0128 Pad) and start/stop via the control terminals Motor adaption plate DMS/FCD Plate for adapting to non Danfoss Bauer motors 175N2115 Membrane DMS/FCD Membrane for preventing condensation 175N2116 Plug kit for LCP2 Plug for LCP2 for mounting in the terminal box.
  • Page 30 (M12). Type Description Ordering no. Internal brake resistor FCD 303-307 Brake resistor for mounting inside the terminal 175N2154 Internal brake resistor FCD 311-335 Brake resistor for mounting inside the terminal 175N2117 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 31 : Recommended minimum value based upon PVC insulated cober cable, 86 degrees Fahrenheit (30 degree Celsius) ambient temperature with normal heat dissipation See dimensions of Coiled wire brake resistors in instructions MI.90.FX.YY MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 32 Decentral Solutions Externally mounted brake resistors in general No use of aggressive cleaning solvents. Cleaning solvents must be pH neutral. See Dynamic braking for dimensioning of brake resistors. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 33: Communication

    Profibus communicates between devices from different in each telegram. Furthermore, you would tend to manufacturers without specific interface adjustments control this information from a PC or an interface device MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 34 • I/O based transmission principle, high DeviceNet protocol efficiency DeviceNet is a communications link that connects • Unified planning tool (e.g. CMD software) industrial devices to a network. It is based on MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 35 14 variable frequency drives of different series on the same InterBus network FC Protocol An RS-485 interface is standard on all Danfoss variable frequency drives allowing for up to 126 units in one network. The FC protocol has a very simple design described in Serial Communication.
  • Page 36: Good Installation Practice

    The T63 and T73 installation boxes have additional looping terminals for 2 X 24 V with 0.15 in (4 mm) Connected sensors can be supplied separately from the control back up supply. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 37 Decentral Solutions Example of power and bus looping MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 38 2. If the IP 65 brake resistors recommended by Danfoss are used the cable will only be exposed to the continuous current of the brake resistor. If the brake resistor becomes overheated it will disconnect itself.
  • Page 39 Decentral Solutions Example of decentral cable dimensioning MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 40: Servicing The Danfoss Decentral Products

    Decentral Solutions Service to fail. In case of a failure in the electronic part, Breakdown of Danfoss drives or geared motors only just remove the six screws, unplug the electronic occur under exceptional circumstances. As downtime part and plug in a new one.
  • Page 41: Introduction, Dms 300

    Decentral Solutions DMS 300 Series MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 42: Operating Instructions

    DMS may cause equipment failure, serious proper ESD equipment should be used to prevent injury or death. Follow this manual as well as national possible damage from occurring. and local rules and safety regulations. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 43: Mechanical Details, Dms 300

    Decentral Solutions Description Wall mounting The Danfoss DMS is an advanced electronic motor For best cooling, the DMS unit should be mounted starting system. It performs six main functions; vertically. If needed, horizontal mounting is allowable. Start control, including soft start.
  • Page 44: Ventilation

    104 deg. F. (40 deg. C.) (Heat loss of DMS at rated current is 0.025 HP (18 watts) approx.). 100% 40 (140) 50 (122) 60 (140) °C (°F) Temperature Derating curve for temperature MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 45: Electrical Connections, Dms 300

    DMS allow two cables to connect two motors in parallel to one DMS. 177ha012.10 Maximum cross section: 0.15 in sq. (10 AWG) Rev310103 Connect Control Supply / AS-i Interface at the terminals provided. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 46 Decentral Solutions Contacts used for controlling these inputs should be low voltage, low current rated (Gold flash or similar) Maximum cross section: 0.1 in (12 AWG) Use cables complying with local regulations. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 47: Motor Thermistors

    The voltage of the DMS is dangerous whenever the equipment is connected to the AC line. Ensure the DMS is correctly connected and that all safety measures have been taken before switching on the supply. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 48: Electrical Schematic

    Decentral Solutions Electrical Schematic MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 49: Setting Up Dms 300

    Extended versions. Start/ stop profile setting Choose the required Start/ Stop profile which is most suited to the application. Use DIP switches A1-A4 to set the start/stop profile. Some examples are shown below. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 50: Start/ Stop Profile Setting Table

    2 (A2) 3 (A3) Voltage Profile Performance Performance (A1) (A4) Time time (sec) # (sec) # Equivalent to Coast to stop 0.25 Fastest 0.75 Coast to stop Slowest Fastest Fastest Slowest Slowest MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 51: Trip Class Selection

    Value (Amps) FLC=4.3 Amps FLC=2.9 Amps 2 (B2) 3 (B3) 4 (B4) 5 (B5) 6 (B6) 6.3 Amps, when B2-B6 0.1+3.2+0+0.8+0+0.2 0.1+0+1.6+0.8+0.4+0 are all On = 4.3 =2.9 See remark See remark MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 52: Completing The Installation

    Completing the installation: To complete installation, fit the DMS Electronics module to the DMS Installation box and secure with the screws provided. Recommended tightening torque for the screws is between 2.5 and 3 Nm. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 53: Operation Details, Dms 300

    +24VDC to the Brake Release input (124). NOTE Mains supply to the DMS is required for the operation of Brake Release. The Electromechanical brake supply is not short-circuit protected. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 54: Description Of As-I Profiles Used With Dms

    Both inputs must be active for DMS to Start. If AS-i bus is used for control, the binary Reset/Coasting stop inverse input must be held active (i.e. connected to +24 VDC) Configuring DMS with a Slave address: MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 55: Fault Procedure

    (terminals 31A & 31B). Four (4) Phase Loss Check supply for missing phase. This is active anytime during start. Five (5) Welded Direction Change Relay Replace unit. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 56: Specification And Order Codes, Dms 300

    Continuous Ratings (Not bypassed) at 104 deg. F (40 deg C.) Ambient Temperature, < 3000 feet (1000 m) Duty Cycle No. of starts per hour Start Time (sec.) For ambient temperature or altitude conditions beyond those listed contact Danfoss. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 57: Ordering Type Code

    Bussmann, British style, BS88, Type CT, 690 V, Max pre-fuses: DMS 300 meets Type 1 co-ordination 20 Amps rated - Part no: 20CT with properly rated HRC fuses. Use type gG 25A, 415 VAC or equivalent HRC fuses. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 58: Special Variants

    B DMS Unit To Motor 5/L3 6/T3 3-PHASE SUPPLY (POWER-BUS) The service switch used for providing isolation to only the motor. To other Decentral controllers Examples of connection of Service switch MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 59: Details Of Profibus Connectivity

    1 Byte inputs, 1 Byte outputs fieldbus controller LSPM2 identifier 0409 hex addressing Node ID: 1-99 set by DIP switch SW3 baud rate up to 12Mbaud, automatic detection MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 60: Table Of Bits In Control And Status Word

    Profibus connector PCB 4 x M12 inputs number 4 x M12 female socket IP67 M12 female socket Pin 1: DC 24 V connection Pin 2: NC (not connected) Pin 3: DC 0 V Pin 4: input MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 61: Profibus Address Setting: Dip Switch Sw3

    DIP 5 DIP 6 DIP 7 DIP 8 The address 00 is not allowed. Also all positions not listed in the table are not allowed. In those cases address 126dec is used. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 62: Introduction To Fcd 300

    The software version number can be seen from parameter 640 Software version no. NOTE This symbol indicates something that should be noted by the reader. Indicates a general warning. This symbol indicates a warning of high voltage. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 63: High Voltage Warning

    4. The ground leakage currents are higher than 3.5 mA. Warning: It can be extremely dangerous to touch the electrical parts even when the AC line supply has been disconnected. For FCD 300: wait at least 4 minutes. 195NA194.10 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 64: Technology

    Variable AC voltage depending on supply voltage. Variable frequency: 0.2 - 132 / 1 - 1000 Hz. 8. Control card Here is the computer that controls the inverter which generates the pulse pattern by which MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 65 Danfoss Bauer geared motor (3 in one solution). of harmonic electrical supply interference. This gives The basic design with a plugable electronic part and a good power factor (lower peak current), which a flexible and "spacious"...
  • Page 66 (Digital input), see parameter 128 Thermal motor protection. NOTE This function cannot protect the individual motors in the case of motors linked in parallel. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 67: Ce Labeling

    1000 Volt AC and the 75 - 1500 Volt DC voltage ranges. ignition by arcs, sparks or hot surfaces, produced either Danfoss CE labels in accordance with the directive and in normal operation or under specified fault conditions. issues a declaration of conformity upon request.
  • Page 68 EN 50014:2000. • The FCD must be installed with appropriate ground connecting according to local/national regulations. • The installation, inspection and maintenance of electrical apparatus for use in combustible dust, MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 69: Installation, Fcd 300

    Space for cable inlets and service switch handle 4-6 in (100-150 mm) Spacing for mechanical installation All units require a minimum of 4 in (100 mm) of air from other components above and below the enclosure. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 70: Mechanical Installation

    The or might be delivered pre mounted on a Danfoss Bauer specified resistance against mechanical vibrations does (geared) motor. Please contact the Danfoss Bauer not cover the mounting onto a non-Danfoss Bauer sales organization for further information.
  • Page 71 Mount the terminal box onto the motor by the 4 sealing screws and the gasket supplied. Use the supplied star washers for securing PE connection according to EN 60204. The screws must be tightened with 5 Nm. Allowed mounting positions MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 72 Decentral Solutions Bottom view of FCD 303-315 Bottom view of FCD 322-330 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 73: General Information About Electrical Installation

    Make sure they are not loosened, removed, or violated in any way. Shielded/armoured cables The shield must have low HF impedance, which is achieved by a braided shield of copper, aluminium or MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 74 > 3.5 mA AC. It must be connected the greatest possible surface area. to an ground connection complying with the local rules for high leakage current equipment. The numbering refers to the figure. Proper installation grounding MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 75: Emc-Correct Electrical Installation

    - Avoid installation with twisted shield ends (pigtails), since this ruins the shielding effect at high frequencies. Use cable clamps instead. - Don’t remove the cable shield between the cable clamp and the terminal. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 76 Z is rarely stated by cable manufacturers, but it is often possible to estimate Z by looking at and assessing the physical design of the cable. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 77: Grounding Of Shielded/Armoured Control Cables

    This problem is resolved by attaching one end of the shield to the ground via a 100 nF capacitor (short pin length). MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 78: Diagram

    J1 and J2 must be removed at IT mains and delta grounded mains with phase to earth voltage > 300 V also during ground failure. J1 and J2 can be removed to reduce leakage current. Caution: No correct RFI filtering. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 79: Location Of Terminals

    Decentral Solutions Location of terminals T11, T12, T16, T52, T56 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 80 Decentral Solutions T22, T26, T62, T66versions with service switch MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 81 Decentral Solutions T73 version with motor plug and sensor plugs Version is supplied from Danfoss with wiring as shown T63 version with service switch (no motor plug) MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 82: Electrical Connection

    / Y). The correct connection mode and voltage can be read from the motor nameplate. NOTE In motors without phase insulation paper, an LC filter should be fitted on the output of the variable frequency drive. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 83: Ac Lines And Motor Connection With Service Switch

    PE = protective ground Motor cables See Technical data for correct sizing of motor cable cross-section and length. Always comply with national and local regulations on cable cross-section. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 84: Motor Thermal Protection

    Dimension the cross-section of the brake cable to match the brake torque. See chapter Dynamic Braking in the Design Guide MG.90.FX.YY for sizing of brake resistors. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 85: Electrical Installation, Control Cables

    100 nF capacitor the controlling unit (use the instructions for the unit between the shield and the chassis. in question). In connection with very long control MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 86: Connection Of Sensors To M12 Plugs For T73

    Terminal 204 = +24 V MG.04.BX.YY, digital inputs terminals 18, 19, 29, 33. Terminals 201/202 can be used for a separate Terminals 203/204 are used for sensor supply. 24 V supply. Terminal 203 = common MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 87: Electrical Installation, Control Terminals

    24 V back up supply. V1 Operating Instructions (MG.90.AX.YY), VLT 2800/FCD 300 DeviceNet Operating Instructions (MG.90.BX.YY) or FCD 300 AS-interface Operating Instructions (MG.04.EX.YY). PC communication Connection to terminals P and N. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 88: Connection Examples

    Decentral Solutions Connection examples NOTE Avoid leading the cables over the plugs to the electronics. Dont loosen screw fixing the spring for the PE connection. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 89 Par. 304 Digital input = Coasting stop inverted [2] Par. 305 Digital input = Jog [13] Par. 314 Analog input = Feedback [2] Par. 315 Terminal 60, min. scaling = 4 mA MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 90 Par. 304 Digital input = Coasting stop inverted [2] Par. 305 Digital input = Preset ref., lsb [22] Par. 307 Digital input = Preset ref., msb [23] Setup 1 contains the following preset references: MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 91 See also par. 138, 139, 140 Mechanical brake with accelerator winding Par. 302 Digital input = Start [7] Par. 304 Digital input = Coasting stop inverted [2] See also par. 138, 139, 140 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 92 VLT frequency converter. Par. 307 Digital input = Pulse input [30] Par. 343 Precise stop function = Counter stop with reset [1] Par. 344 Counter value = 100000 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 93: Programming, Fcd 300

    As a supplement to the display, there are three LEDs for voltage (ON), warning (WARNING) and alarm (ALARM). All variable frequency drive parameter Setups can be MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 94 016 Local reverse. The [FWD/REV] key is only active when parameter 002 Local/remote operation is set to Local control. [START] is used to start the variable frequency drive. Is always active, but cannot override a stop command. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 95 MODE] the display will indicate the mode of the variable frequency drive. Switch mode by using [+/-] key [HAND...AUTO] In [HAND] mode the reference can be changed by [+] or [-] keys. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 96 Display mode II, unless the key is held down for less than approx. 1 sec., in which case the system always reverts to Display mode I. REF% TORQUE CURR A 50.0 Hz SETUP MOTOR IS RUNNING MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 97: Parameter Selection

    The Menu mode allows choosing and changing into groups. Selection of parameter group is all parameters as required. However, some effected using the [< >] keys. The following parameter groups will be accessible: MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 98 (saved) when acknowledgment is given [OK]. Change of numeric data value If the selected parameter is represented by a numerical data value, a digit is first chosen using the [< >] keys. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 99: Operation & Display

    There is a choice of four Setups (parameter Setups), parameter 013 Local control). which can be programmed independently of one = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 100 (COPY TO SETUP 1) parameters can be programmed in four individual parameter Setups. Shifts between Setups can = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 101 This (MOTOR THERMAL [%]) [13] is used when downloading to a variable frequency = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 102 Hz in Open loop. In Closed loop the reference unit is selected in parameter 416 Process units. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 103 LCP Remote-operated control as parameter 100 = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 104 Remote-operated control Not active (DISABLE) as parameter 100 [4]: the present reference will Active (ENABLE) = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 105 In this parameter you can select whether it should be possible or not to switch between Auto- and Hand = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 106 Quick Menu. This parameter enables the user to visualize different situations using the Status LED. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 107 Decentral Solutions Description of choice: Select the function to be visualized. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 108: Load And Motor

    Process closed loop is not active if a have been selected. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 109 This is where to set the rated motor voltage U for either star Y or delta = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 110 Description of choice: can be set as follows: Interrupting AMT: = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 111 Reduces the output voltage when running at low (COAST/DELAY TIME) load for avoiding resonance phenomena. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 112 It is used in particular for applications in which a cone anchor motor is applied. The cone = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 113: Dc Braking

    The cut-out value is 3 k . = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 114 Select Thermistor trip [2] if you want a trip when the connected thermistor becomes too hot. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 115 Small motors (< 1.0 HP) normally compensation may lead to instability. require a high start voltage. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 116 This parameter is used to keep the motor until the point when the brake is released. (holding torque) at start/stop. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 117: Motortype, Par, 147 - Fcd 300

    If 1.0 is selected, this corresponds to the AC brake being inactive. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 118: References & Limits

    The parameters mentioned can be active in both closed and open loop. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 119 It is possible to have both references and external references simultaneously. In parameter 214 = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 120 Process reg, closed loop [3] Par. 416 Sine shaped (S-SHAPED) Sine shaped (S-SHAPED 2) = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 121 2 by activating Ramp 2 via a digital input. Description of choice: Set the required ramp-up time. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 122: Reference Function

    Relative [1] the defined Preset references (par. 215-218) are added as a percentage of the total of the present = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 123 If Sum [0] is selected, one of the adjusted preset references (parameters 215-218 Preset = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 124 46 and via the relay output. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 125 416 Process units. has reached the resulting reference. The signal = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 126 Description of choice: Enter the frequencies to be avoided. See also parameter 229 Frequency bypass, bandwidth. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 127: Inputs And Outputs

    Settings are identical for terminal 29 and 33. Selection Delayed speed change is only relevant for Profibus units. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 128 (in Hz). The output frequency can now only be changed via Speed up and Slow down . = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 129 = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 130 If reference signals are connected to more than = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 131 Description of choice: - overruled to stop with subsequent trip [5] Set the required current value. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 132 (BELOW FREQUENCY HIGH) [12] 0-20 mA/ 4-20 mA. Output current higher than I par. 223 = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 133 The AC line programmed range in parameters 223 and 224. voltage lies within the voltage limits. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 134 68 °F (20 °C), and 20 mA corresponds to 212 °F (100 °C). = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 135 = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 136 Sensor, PLC and other hardware corresponds to this setting. NOTE Only active for speed-compensated stop. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 137: Special Functions

    = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 138 Pulses/s (PULSE/S) Units/s (UNITS/S) Units/min. (UNITS/MI) Units/h (UNITS/H) = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 139: Pid Functions

    100 Configuration the unit of to regulate speed and one to regulate processes. reference/feedback is always rpm. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 140 1.6 oscillations per second in parameters 215 to 218 Preset reference. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 141: Handling Of Feedback

    This is done by programming a start frequency in parameter 439 Process PID start frequency. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 142 Decentral Solutions = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 143 This might be an advantage, e.g. if there is a great amount of noise on the signal. See drawing. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 144 The voltage at 0 Hz is set in parameter 133 Start voltage. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 145 = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 146 Thereby a pure differentiator gain is obtained = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 147 = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 148 A change of selection will not become active until the AC line voltage has been disconnected and reconnected. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 149: Serial Communication For Fcd 300

    Each character is secured via a parity bit, which is set at "1" when it reaches parity (i.e. when there is an equal number of 1’s in the 8 data bits and MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 150 Bit 7 = 1 (address format 1-126 active) Bit 0-6 = Adjustable frequency drive address 1-126 Bit 0-6 = 0 Broadcast The slave sends the address byte back unchanged in the response telegram to the master. Example: MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 151 If the command cannot be performed the slave sends this response: 0111 Command cannot be performed and gives the following fault report in the parameter value (PWE): Parameter commands and responses (AK). MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 152 To be able to read a text via the PWE block the Error code must be read. parameter command (AK) must be set to ’F’ Hex. PKE = 1267 Hex (read parameter 615 Error code.) IND = 0001 Hex - Index no. 1. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 153 PKE = E0CA Hex - Write for parameter 202 Output frequency high limit, f IND = 0000 Hex = 0000 Hex HIGH = 03E8 Hex - Data value 1000, corresponding to 100 Hz, see conversion. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 154: Control Word According To Fc Protocol

    Example: Parameter 201 Output frequency, low limit f a conversion factor of 0.1. If you wish to preset the MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 155 "shut off"), so that it coasts to a standstill. Bit 03 = ’1’ causes the variable frequency drive to be able start the motor if the other starting conditions have been fulfilled. Note: In parameter 502 Coasting stop MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 156: Status Word According To Fc Profile

    Bit 02 = ’1’. The variable frequency drive can start the motor when a start command is given. Bit 03, No trip/trip: Bit 03 = ’0’ means that the variable frequency drive is not in fault mode. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 157: Control Word According To Fieldbus Profile

    Bit 11 = ’0’ means that the motor is not running. Bit 11 = ’1’ means that the variable frequency drive has a start signal or that the output frequency is greater than 0 Hz. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 158: Status Word According To Profidrive Protocol

    Bit 07, Reset: See description under Control word according to FC protocol. Bit 08, Jog 1: Bit 08 = "1" means that the output frequency is determined by parameter 09 Bus jog 1. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 159 Bit 06 = ’1’ after reset of a trip, after activation of OFF2 format: 0-16384 (4000 Hex) 0-100% (Par. 204 or OFF3 and after connection of AC line voltage. Start Minimum ref. - Par. 205 Maximum ref.). MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 160 0 - ±32767 (±200%). 16384 (4000 Hex) corresponds to 100%. Output frequency has the following format: 0-16384 (4000 Hex) 0-100% (Par. 201 Output frequency low limit - Par. 202 Output frequency high limit). MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 161: Serial Communication

    Coasting Motor running Motor running Motor running = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 162 Decentral Solutions Logic or [3] Dig. input Ser. port Function Coasting Coasting Coasting Motor running = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 163 Quick stop DC braking Quick stop DC braking Quick stop Motor running Motor running = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 164 Function Dig. input Ser. port Function Stop Clockwise Start Counter-clockwise Start Counter-clockwise Start Counter-clockwise = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 165 Setup 3 Setup 4 Logic and [2] Dig. Dig. Setup Setup Setup Setup Setup = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 166 It is possible to choose between two different control word profiles. Description of choice: Select the desired control word profile. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 167 Frequency [Hz], parameter 518: Gives the output frequency from the variable frequency drive. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 168 (sum of analog/pulse/serial communication) in the range from Minimum reference, Ref Maximum reference, Ref = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 169: Technical Functions

    601 is reset to zero Hours run. This parameter cannot be selected via serial communication. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 170 4. Connect the AC line voltage. 5. The variable frequency drive automatically undertakes a test of the control card. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 171 Parameter 642 Nameplate: Power card identification: The ID number of the unit’s power part appears here. Example: 1.15 = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 172 This means, that a control card only can be downgraded to a lower performance version. = factory setting. () = display text [] = value for use in communication via serial communication port MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 173: All About Fcd 300

    Danfoss has chosen a solution in which the brake resistor is not integrated into the variable frequency Calculation of brake resistance drive.
  • Page 174 P is smaller than P PEAK PEAK, , as the power is reduced by the efficiency of MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 175 How to calculate optimum DC-brake cut in frequency: Slip S= Synchronous speed [1/min] f=frequency p = no. of pole pairs = speed of the rotor DC-brake cut in frequency = Brake cable Max. length [ft]: 30 ft (10 m) MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 176 Decentral Solutions Safety functions in connection with installation if the brake current is too high. Danfoss’ 40% When a brake resistor is installed, the best brake resistors contain a KLIXON switch. Flat possible endeavours should be made to avoid pack resistors are self-protecting.
  • Page 177: Internal Brake Resistor

    Internal Brake Resistor Mechanical dimensions of flatpack brake resistors For occasional braking or braking with low duty cycle 100 W 200 W internally mountable brake resistors are available. (See Accessories for FCD 300). MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 178 Decentral Solutions Dimensions of mounting brackets MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 179: Special Conditions

    - There may be max. 300 V between phase and ground. A motor thermistor connected to terminals 31a-31b must be double isolated to obtain PELV. Danfoss Bauer provides double isolated thermistors. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 180: Ground Leakage Current And Rcd Relays

    See parameter 409 Trip delay overcurrent, I depends on impedance and motor frequency. An extreme overload will cause the switching frequency to be derated to 3000 Hz. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 181: Du/Dt On Motor

    1. DC intermediate circuit coils. 2. Inverter. Below are the typical values measured at a distance of 3 ft from the unit at full load: FCD 303-335 3 x 400 V: 52 dB(A). MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 182: Temperature-Dependent Switch Frequency

    Vibration and shock The variable frequency drive has been tested according to a procedure based on the following standards: IEC 68-2-6: Vibration (sinusoidal) - 1970. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 183: Air Humidity

    75%, e.g. in case of part loads. load, it is important to maintain harmonic currents This also means that the efficiency of the variable frequency drive does not change even if other MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 184: Power Factor

    The lower the power factor, the higher the I for the same HP (kW) performance. In addition, a high power factor indicates that the different harmonic currents are low. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 185: Emission Test Results According To Generic Standards And Pds Product Standard

    30 ft (10 m) shielded/armoured motor cable FCD 322-335 15 ft (5 m) shielded/armoured motor cable For 30 ft (10 m) cable please contact Danfoss. NOTE FCD 300 with class 1A RFI-filter is a product of the restricted sales distribution class according to IEC 61800-3.
  • Page 186 - / 4 kV, 2 10 Vrms DM: Differential mode DCN: Direct coupling network (5 kHz) CM: Common mode 1. Injection on cable shield. CCC: Capacitive clamp coupling (5 kHz) 2. Electromagnetic clamp. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 187: Aggressive Environments

    The FCD 300 holds a log with valuable information on failure. Information on the most recent 10 Local Control Panel faults is stored and indexed in three different parameters to help diagnosis. LCP2-plug MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 188 Yellow No warning is present Flashing Flashing while warning situation is present Green The unit is supplied by line power or 24 V DC Line power or 24 V DC is missing MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 189: Status Messages

    The voltage or current signal on terminal 53 or Warning yellow 60 is below 50% of the preset value in parameter Alarm 309 or 315 Terminal, min. scaling. Trip locked yellow and red WARNING/ALARM 2: Live zero fault MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 190 Note: Voltage warning high The inverter’s peak current limit (approx. 200% of (warning 5) will thus also be able to generate an alarm 7. rated output current) has been exceeded. The warning WARNING/ALARM 8: Undervoltage MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 191 Process regulation, closed loop, bit 008000 temperature of the internal heatsink has dropped to Out of frequency range in extended status word will be active, but there will not be a warning in the display. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 192: Warning Words, Extended Status Words And Alarm Words

    - The motor current in at least one of the motor phases is too low. - The motor in use is probably too small for AMT calculations to be performed. ALARM 51: AMT Fault re. nameplate data MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 193 FCD 307 178B1485 FCD 315 178B1486 FCD 330 178B2301 The parts can be downsized one size simply by selecting the correct motor size, and the Profibus functionality can be changed/eliminated in Parameter 678. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 194: General Technical Data

    All digital inputs are galvonically isolated from the supply voltage (PELV) and other high-voltage terminals, and can be functionally separated from other control terminals by opening switch S100. See section entitled Galvonic Isolation. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 195 Accuracy on frequency output ................. Max. error: 0.2 % of full scale Resolution on frequency output ........................10 bit The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. See section entitled Galvonic Isolation. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 196 Power consumption with/without power supply ................. <1W/5-12W Reliable galvanic isolation: Full galvanic isolation if the external 24 V DC supply is also of the PELV type. Sensor supply (T63, T73): Terminal nos ..........................201, 202, 203, 204 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 197 EMC standards used, Emission ..............EN 50081-1-2, EN 61800-3, EN 55011 EMC standards used, immunity ......................... EN 61000-6-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6 See section on special conditions in the Design Guide MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 198 Monitoring of the intermediate circuit voltage ensures that the variable frequency drive cuts out if the intermediate circuit voltage is too low or too high. • The variable frequency drive is protected against ground fault on motor terminals U, V, W. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 199: Technical Data, Line Supply 3 X 380 - 480V

    If you want to maintain UL/cUL branch circuit fuses according to NEC should be used. Alternatively a circuit braker Danfoss type CTI 25 MB or equivalent should be used. To be placed for protection in a circuit that is capable of supplying a maximum of 100,000 amps for fuses / 10,000 amps for circuit brakers.
  • Page 200: Available Literature

    Design Guide - Decentral Solutions ....................MG.90.FX.YY Communication with FCD 300: Profibus DP V1 Operating Instructions ....................MG.90.AX.YY DeviceNet Operating Instructions ...................... MG.90.BX.YY AS-i Operating Instructions ....................... MG.04.EX.YY X = version number YY = language version MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 201: Factory Settings

    Conversion index: This number refers to a conversion figure to be used when writing or reading via serial communication 0.01 with an adjustable frequency drive. 0.001 0.0001 0.00001 See also Serial communication. MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 202 Decentral Solutions Data type: Data type shows the type and length of the telegram. Data type Description Integer 16 Integer 32 Unsigned 8 Unsigned 16 Unsigned 32 Text string MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 203 DC hold voltage Brake cut out value 3.0 Hz Brake cut in frequency 3.0 Hz Current, minimum value Leak reactance depends on motor selected AC brake factor 1.30 Reset voltage vector Motor type General MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 204 Warn. Low frequency 0.0 Hz Warn. High frequency 132.0 Hz Warn. Low Feedback -4000.000 Warn. High Feedback 4000.000 Frequency bypass, 0 Hz (OFF) bandwidth Frequency bypass 1 0.0 Hz Frequency bypass 2 0.0 Hz MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 205 Pulse Max. 29 5000 Hz Term. 46 digital output No function Term. 46 Max. pulse output 5000 Hz Precise stop function Normal ramp stop Counter value 100000 pulses Speed comp delay 10 ms MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 206 Proc. PID differentiation time Off (0.00 s). Proc. PID diff. ampl. limit Proc. PID lowpass filter time 0.02 s Flying start Not possible Speed PID feedforward factor 100% Controller range 10 % Brake voltage reduce MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 207 Data readout: Status word Data readout: Inverter temperature Data readout: Alarm word Data readout: Control word Data readout: Warning word Data readout: Extended status word Data readout: Pulse count Data readout: Pulse input, term. 29 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 208 Nameplate: Communication option type Nameplate: BMC software identification Nameplate: Unit identification for communication Nameplate: Software parts no. Software version BMC software identification Power card identification Configure Control Card Depends on unit type MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 209: Index

    ............Constant torque ........ETR - Electronic Thermal Relay ..............Construction ............Extra protection ............... Control cable ......... Extreme operating conditions .............. Control cables ..........Control of mechanical brake ............Control principle MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 210 ................ LCP 2 ............Profibus DP-V1 ............LCP 2 plug, optional ........... Parallel connection of motors ..............LCP copy ............PC communication ............Leakage reactance ............PC Software tools ............Load compensation MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 211 Relay output 1-3 ............. Reset function ..............thermistor ............. Reset voltage vector ............Telegram Profile ..........Resonance dampening ............Telegram Structure ..............RFI switches ............Telegram Traffic ......Temperature-dependent switch frequency ..............Terminal 42 MG.90.F2.22 - VLT is a registered Danfoss trademark...
  • Page 212 ..Warning words, extended status words and alarm words ..........Warnings/alarm messages ..............24 V DC ............24 V DC supply ............24 V external supply ............4-20 mA reference ..............4-Setup: MG.90.F2.22 - VLT is a registered Danfoss trademark...

This manual is also suitable for:

Vlt fcd 300

Table of Contents
