  • Page 1 At the end of this document you will find links to products related to this catalog. You can go directly to our shop by clicking HERE. HERE...

  • Page 2: Table Of Contents

    Application Examples Product Design Guide Ordering Form PC Software Tools Accessories Communication Good Installation Practice Servicing the Danfoss Decentral Products 2 Introduction to FCD 300 Safety High Voltage Warning These Rules Concern your Safety Warning against Unintended Start Technology CE Labelling...
  • Page 3 Parameter Group 6-** Technical Functions 5 All About FCD 300 Brake Resistors Dynamic Braking Internal Brake Resistor Special Conditions Galvanic Isolation (PELV) Earth Leakage Current and RCD Relays Extreme Operating Conditions ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 4 Immunity Test Result according to Generic Standards, PDS Product Standards and Basic Standards Aggressive Environments Cleaning Status Messages Warnings/Alarm Messages Warning Words, Extended Status Words and Alarm Words General Technical Data Available Literature Factory Settings Index ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 5 ® 1 The Decentral Concept Decentral FCD 300 Design Guide ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 6: The Decentral Concept

    1.1 Introduction Danfoss was the world's first company to manufacture and supply frequency converters for infinitely variable speed control of three-phase AC motors. Until then, AC motors had to operate at the speed determined by the frequency of the main power supply.

  • Page 7: Decentral Design Benefits

    This of course increases the cost of the drive. This increase will be more than set off by savings in expenses for cabinets and cables. The cable saving potential is considerable, as will be demonstrated by the following example. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 8 The drives are distributed equidistant with the distance L between each drive and the distance h between each row and also with a distance h from the centralised power entry/cabinet location to the first row. There are n rows, and N drives in each row. Illustration 1.3: Decentralised installation ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 9 The concept of modularisation is known from equipment like PC’s and cars. Modules with well-described functionalities and interfaces are used in these products. The same concept can be applied to manufacturing, even though specific physical constraints play a role. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 10 I/O-stations, the extension will be limited. Decentralised products from Danfoss can even be used as remote I/O stations to connect sensors to the fieldbus and reduce direct costs even more.
  • Page 11 1.2.6 Minimum Thermal Losses Danfoss frequency converters feature the unique Voltage Vector Control (VVC) switching principle to generate motor voltages. Due to the VVC principle, power losses in the motor are similar or less than the losses in a motor connected to mains. Thermal losses are minimised and overheat is prevented. At the same time, the VVC principle ensures nominal torque at nominal speed and eliminates bearing currents.
  • Page 12 These concerns are more or less irrelevant if not applied to all elements and standard AC motors are normally designed without these concerns in mind – stressed by integrated fans and cooling ribs both difficult to clean. Danfoss has met the challenge by designing a range of aseptic geared motors. These motors have no fans and only smooth surfaces.
  • Page 13 Build-up of water inside enclosures can be prevented by membranes that prevents fluids to penetrate but allows for vapour to pass, as known from fabrics used for outdoor clothing. A special cable gland with this kind of material is offered by Danfoss to eliminate this problem. The cable gland should be used in applications exposed to frequent temperature fluctuations and humid environments as in equipment used only during daytime where the inside tem- perature tends to fall to the ambient temperature during the night.

  • Page 14: Application Examples

    1.3 Application Examples Danfoss has completed a wide range of applications in many different industries. This has given us a valuable experience that has influenced the latest development of our decentralised products. In the following we provide illustrative examples of actual installations using Danfoss decentralised products, and the benefit and value these provide for the customer in these installations.
  • Page 15 Less space needed for the new solution 1.3.4 Food Conveyor Illustration 1.17: Efficient space utilisation in the food in- Illustration 1.16: Efficient space utilisation in the food in- dustry with decentralised motor controls from Danfoss dustry with decentralised motor controls from Danfoss Benefits: •...
  • Page 16 No expensive wiring: All motors use existing power cables, pipes and local switches • All motor controls can be controlled from the existing centralised cabinet via Profibus Illustration 1.18: Retrofitting on existing application with speed control ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 17: Product Design Guide

    1.4.1 The Decentralised Product Range The Danfoss decentralised products comprise for Frequency Converters VLT Decentral FCD 300 and VLT Drivemotor FCM 300 in their different installation/ mounting concept. This Design Guide gives detailed information about the FCD 300 products only. For further information about FCM 300 please see the FCM Design Guide: MG03Hxyy ®...
  • Page 18 ® Decentral FCD 300 Design Guide 1 The Decentral Concept 3. “Pre-mounted” on Danfoss Bauer geared motors • A fixed combination of motor and electronics supplied by one supplier • Easy mounting, only one unit • No need for screened motor cable •...
  • Page 19 The bottom section contains Cage Clamp connectors and looping facilities for power and fieldbus cables well protected against dust, hosing and cleaning agents. Service switch mounted on the right side (seen from motor drive end). A lockable switch integrated in the enclosure – disconnecting the motor or drive. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 20 Electronic motor protection and reversing are always included Extended functionality 24 V external back up of control and communication Brake control and supply of electromechanical brake Dynamic braking see Brake Resistors (brake resistor is optional ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 21 T73 - Installation box, wall mount, metric thread, double side, motor plug, sensor plugs, Viton gasket Coating (positions 25-26): The IP66 enclosure offers protection of the drive against aggressive environments, which practically eliminates the need for coated printed circuit boards. • C0 - Non coated boards ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 22: Ordering Form

    ® Decentral FCD 300 Design Guide 1 The Decentral Concept 1.4.13 Ordering Form ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 23: Pc Software Tools

    Motor adaption plate Aluminium plate with holes drilled to fit the FCD box. Must be fitted locally for the actual 175N2115 motor. Plate for adapting to non Danfoss Bauer motors Venting Membrane Membrane preventing water build-up due to condensation inside enclosures.
  • Page 24 Therm. relay : Brake current setting of thermal relay Code number : Order numbers for Danfoss brake resistors Cable cross section : Recommended minimum value based upon PVC insulated cober cable, 30 degree Celsius am- bient temperature with normal heat dissipation See dimensions of Coiled wire brake resistors in instructions MI.90.FX.YY...

  • Page 25: Communication

    More than 2,000 products from approximately 250 Profibus vendors are available today. More than 6.5 million devices representing a huge variety of products are installed and successfully used in more than 500,000 applications in manufacturing and process automation. Danfoss Drives solution offers a cost optimal Profibus solution •...
  • Page 26 No need for extensive telegrams in the PLC or IPC. A second master who supports DP V1 can handle set-up tasks DP V1 is only possible for Master communication-cards which support Masterclass 2 specification. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 27 The CAN protocol was originally developed for the European automotive market to be used in exchange for expensive wire harnesses in automobiles. As a result, the CAN protocol offers fast response and high reliability for demanding applications like ABS brakes and air bags. Danfoss concept offers the cost optimal DeviceNet solution •...

  • Page 28: Good Installation Practice

    Decentral FCD 300 Design Guide 1 The Decentral Concept 1.5.6 FC Protocol An RS-485 interface is standard on all Danfoss frequency converters allowing for up to 126 units in one network. The FC protocol has a very simple design Serial Communication described in .
  • Page 29 ® 1 The Decentral Concept Decentral FCD 300 Design Guide Illustration 1.19: Example of power and bus looping ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 30 FCD will interrupt the flow of current. If the IP 65 brake resistors recommended by Danfoss are used the cable will only be exposed to the continuous current of the brake resistor. If the brake resistor becomes overheated it will disconnect itself. If another type or make of brake resistor, without any power limitation device, is used, the maximum power must be equal to the rated power of the motor.

  • Page 31: Servicing The Danfoss Decentral Products

    1.7 Servicing the Danfoss Decentral Products 1.7.1 Service Breakdown of Danfoss drives or geared motors only occur under exceptional circumstances. As downtime represents lack of production, failures must be located and defective components replaced quickly. Danfoss' decentralised products place great emphasis on addressing these issues. This chapter also describes measures taken to make Danfoss decen- tralised products superior in a service situation.

  • Page 32: Introduction To Fcd

    The software version number can be seen from parameter 640 version no.. This symbol indicates something that should be noted by the reader. Indicates a general warning. This symbol indicates a warning of high voltage. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 33: Safety

    The Protective Extra Low Voltage (PELV) requirements stated in IEC 61800-5-1 are not fulfilled at altitudes above 2000 m (6562 ft.). For 200V frequency converters the requirements are not fulfilled at altitudes above 5000 m (16 404 ft.). Please contact Danfoss Drives for further information.

  • Page 34: Technology

    The unit is flexible in its mounting options for as well stand alone mounting and motor mounting. It is also possible to have the unit pre-mounted on a Danfoss Bauer geared motor (3 in one solution). The basic design with a plugable electronic part and a flexible and “spacious” wiring box is extremely servicefriendly and easy to change electronics without the need for unwiring.
  • Page 35 To give the motor maximum protection against overheating when it is covered or blocked, or if the fan should fail, you can install a thermistor and connect Thermal motor protection. it to the frequency converter's thermistor input (Digital input), see parameter 128 This function cannot protect the individual motors in the case of motors linked in parallel. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 36: Ce Labelling

    Frequency converters must be CE labelled in accordance with the low-voltage directive, which came into force on 1 January 1997. The directive applies to all electrical equipment and appliances used in the 50 - 1000 Volt AC and the 75 - 1500 Volt DC voltage ranges. Danfoss CE labels in accordance with the directive and issues a declaration of conformity upon request.
  • Page 37 The installation, inspection and maintenance of electrical apparatus for use in combustible dusts, must only be carried out by personnel that is trained and familiar with the concept of protection. For a declaration of conformity, please consult your local Danfoss representative. ®...

  • Page 38: Installation

    3.1.2 Mechanical Dimensions, Stand Alone Mounting Mechanical dimensions in mm FCD 303-315 FCD 322-335 Cable Gland sizes M16, M20, M25 x 1.5 mm Space for cable inlets and service switch handle 100-150 mm ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 39 Motor mounted or might be delivered pre mounted on a Danfoss Bauer (geared) motor. Please contact the Danfoss Bauer sales organisation for further information. The frequency converter is cooled by means of air circulation. For the unit to be able to release its cooling air, the minimum free distance above and...
  • Page 40 The specified resistance against mechanical vibrations does not cover the mounting onto a non Danfoss Bauer motor, as the stability of the motor frame and threads are outside Danfoss Drive's control and responsibility and the same applies to the enclosure class.

  • Page 41: General Information About Electrical Installation

    90 degrees. Remember that all noise-filled inlet and outlet cables to a cabinet must be screened/armoured. See also EMC-compliant electrical installation Cable glands It must be assured that appropriate cable glands needed for the environment are chosen and carefully mounted. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 42: Electronics Purchased Without Installation Box

    PE-terminal. 3.3.6 Electronics Purchased without Installation Box If the electronic part is purchased without the Danfoss installation part, the earth connection must be suitable for high leakage current. Use of original Danfoss installation box or installation kit 175N2207 is recommended.
  • Page 43 PE connections, voltage equalising cables and the screen of the communication cable should be connected to the same potential (4). Keep the conductor as short as possible and use the greatest possible surface area. The numbering refers to the figure. Illustration 3.5: Proper installation earthing ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 44: Emc-Correct Electrical Installation

    Screen coverage, i.e. the physical area of the cable covered by the screen. Is often stated as a percentage and should be no less than 85%. The screen type, i.e. braided or twisted pattern. A braided pattern or closed pipe is recommended. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 45: Earthing Of Screened/Armoured Control Cables

    This prob- lem is resolved by attaching one end of the screen to the earth via a 100 nF capacitor (short pin length). ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 46: Diagram

    J1 and J2 must be removed at IT mains and delta grounded mains with phase to earth voltage > 300 V also during earth failure. J1 and J2 can be removed to reduce leakage current. Caution: No correct RFI filtering. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 47: Electrical Installation - Description Of

    ® 3 Installation Decentral FCD 300 Design Guide 3.5 Electrical Installation - Description of 3.5.1 Location of Terminals Illustration 3.6: T11, T12, T16, T52, T56 Illustration 3.7: Versions with service switch ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 48: Mains Connection

    3 Installation Illustration 3.8: T73 version with motor plug and sensor plugs Version is supplied from Danfoss with wiring as shown 3.5.2 Mains Connection Please check that the mains voltage fits the mains voltage of the frequency converter, which can be seen from the nameplate.

  • Page 49: Motor Connection

    Terminal 96 connected to U-phase. Terminal 97 connected to V-phase. Terminal 98 connected to W-phase. The direction of rotation can be changed by switching two phases on the motor terminals. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 50: Mains And Motor Connection With Service Switch

    The total current consumption of the motors is not to exceed the maximum rated output current I for the frequency converter. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 51: Motor Cables

    Dimension the cross-section of the brake cable to match the brake torque. Dynamic Braking Design Guide MG.90.FX.YY See chapter in the for dimensionering of brake resistors. Please note that voltages up to 850 V DC occur on the terminals. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 52: Control Of Mechanical Brake

    In this connection, it may be necessary to break the screen and possibly insert a 100 nF capacitor between the screen and the chassis. Switches S101-104 Bus line coils, leave switches ON ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 53: Connection Of Sensors To M12 Plugs For T63 And T73

    RS485(-), LCP2/PC, green OV, blue VLT 2800/FCM 300/FCD 300 Profibus DP V1 Operating Instructions VLT 2800/FCD 300 DeviceNet Operating Instructions * See (MG.90.AX.YY), (MG. FCD 300 AS-interface Operating Instructions 90.BX.YY) or (MG.04.EX.YY). ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 54: Pc Communication

    The field bus status word at power up might be different (typically 0603h instead of 0607h) until the first valid control word is sent. After sending the first valid control word (bit 10 = Data valid) the status is exactly as in earlier software versions. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 55: Connection Examples

    ® 3 Installation Decentral FCD 300 Design Guide 3.6 Connection Examples Avoid leading the cables over the plugs to the electronics. Don't loosen screw fixing the spring for the PE connection. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 56 Speed up/down using terminals 29/33. Par. 302 Digital input Start Par. 303 Digital input Freeze reference [14] Digital input Speed up Par. 305 [16] Digital input Speed down Par. 307 [17] ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 57 Terminal 53, max. scaling Par. 310 = 10 Volt Par. 314 Analog input Reference Par. 309 Terminal 60, min. scaling = 4 mA Teminal 60, max. scaling Par. 310 = 20 mA ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 58 Start Digital input Coasting stop inverted Par. 304 Analogue input Reference Par. 308 Par. 309 Terminal 53, min. scaling = 0 Volt. Par. 310 Terminal 53, max. scaling = 10 Volt. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 59 Preset reference 4 = 100.00% 3.6.9 Connection of Mechanical Brake Using terminal 122/123 Par. 302 Digital input Start Digital input Coasting stop inverted Par. 304 See also par. 138, 139, 140 ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 60 344 has managed to stop the VLT frequency converter. Digital input Pulse input Par. 307 [30] Par. 343 Precise stop function Counter stop with reset Counter value Par. 344 = 100000 ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 61 ® 4 Programming Decentral FCD 300 Design Guide ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 62: Programming

    [CANCEL] is used if a change to the selected parameter is not to be implemented. [OK] is used to confirm a change to a selected parameter. [+ / -] are used for selecting parameters and for changing parameter values. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 63 . The [FWD/REV] key is only active when parameter 002 Local/remote operation is set to Local con- trol [START] is used to start the frequency converter. Is always active, but cannot override a stop command. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 64 In this mode, all data values for four operating data items with any per- Large display readout been selected as readout via parameter 009 . In taining units are shown, see table. In the example, the following have ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 65 At the bottom of the display, the parameter number and name are given 002 Local/remote operation together with the status/value of the first parameter under the Quick 003 Local reference [Hz] ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 66: Parameter Selection

    The chosen digit is indicated by the digit flashing. The bottom display line selected parameter, following which the underlining in line 4 will flash on shows the data value that will be entered (saved) when signing off with [OK]. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 67: Parameter Group 0-** Operation & Display

    Local operation must be set to [1]. Local reference cannot be set are active. via serial communication. Local operation [1], is selected, the adjustable frequency drive is con- trolled via: ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 68: Setup Configuration

    [OK]/[CHANGE DATA] key has been pushed. The display indi- Setup 2 (setup 2) cates when copying is in progress. Setup 3 (setup 3) Setup 4 (setup 4) Active Setup (ACTIVE SETUP) ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 69 Power [kW] (Power [kW]) feedback, FB and 416 Process units HIGH Power [HP] (Power [HP][US]) Frequency [Hz] gives the output frequency of the frequency converter. Motor voltage [V] (Motor voltage [V]) [11] ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 70 002 by pushing the [DISPLAY STATUS] key. cal/remote operation Remote- , while this parameter has been set to operated control and open loop [1]: The present motor frequency and ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 71 Forced stop, set ref. to 0 [2] is selected if the adjustable frequency drive is to remain stopped when the mains voltage is cut back in. Parameter Local reference is to be zeroed. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 72 Up to 20 parameters can be selected for the user-defined Quick Menu. Please note that this parameter can only be set using Order form an LCP 2 control panel. See Description of choice: The Quick Menu is set up as follows: ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 73: Parameter Group 1-** Load And Motor

    423-428 Voltage/frequency Constant torque (Constant torque) Variable torque low (torque: low) Variable torque medium (torque: med) Variable torque high (torque: high) Variable torque low with CT start (VT LOW CT START) ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 74 This is where to set the value that corresponds to the rated motor speed AMT may not be performed on motors connected in that can be seen from the nameplate data. parallel, nor may setup changes be made while AMT is running. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 75 Start frequency and 131 Voltage at start during start delay time. Regardless of the value assumed by the reference signal, the output frequency equals the setting in parameter 130 Start frequen- ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 76: Dc Braking

    In this parameter, the DC brake time is set at which parameter 132 ETR warning 2 (ETR WARNING 2) brake voltage is to be active. ETR trip 2 (ETR TRIP 2) ETR warning 3 (ETR WARNING 3) ETR trip 3 (ETR TRIP 3) ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 77 Setup in which they voltage clockwise Start frequency/voltage in reference direction [3] or have been selected. This means that you can use the ETR function even when changing between two or more motors. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 78 Relay output 1-3 or 341 Digital output, terminal 46 (optionally also terminal 122 and 123). If this value is set too high, the frequency converter may cut out because of overcurrent. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 79 . The shaft performance can be improved by fine- Description of choice: tuning the leakage reactance X The value can be selected general for most motor brands. Select Danfoss Bauer for optimal settings for Danfoss Bauer gear motors. The leakage reactance X...

  • Page 80: Parameter Group 2-** References & Limits

    The resulting reference can be shown on the LCP control unit's display by rameters mentioned can be active in both closed and open loop. Reference Display readout selecting [%] in parameters 009-012 and can ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 81 Process regulation, closed loop [1] or [3] is selected, the Minimum feedback minimum reference is limited by parameter 414 . Min- imum reference is ignored if the local reference is active. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 82 (set in parameter 221 Current limit I The jog ramp time starts if a jog-signal is given via the LCP control panel, one of the digital inputs or the serial communication port. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 83: Reference Function

    Preset reference Par. 215 2.4 Hz External reference is the sum of the analogue references, pulse referen- Resulting reference 28.4 Hz ces and any references from serial communication. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 84 If the output current exceeds the preset limit I a warning is given. HIGH Warning functions Parameters 223-228 do not work during ramp-up after a start command and after stop command or during stop. The warning ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 85 Description of choice: Function: Enter the frequencies to be avoided. See also parameter 229 Frequency If the feedback signal falls below the preset limit FB , a warning is bypass, bandwidth given. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 86: Parameter Group 3-** Inputs And Outputs

    DC voltage for a given time, see parameters 126, 127 and 132 brake . Please note that this function is only active if the value in param- ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 87 All encoder settings are used in connection with dual track encoders with or reduced by a programmable percentage value set in parameter 219 direction recognition. Catch-up/Slow-down reference A track connected to terminal 29. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 88 1 Volt No function (no operation) Terminal 60, min. scaling has been selected, or if in parameter 315 value higher than 2 mA has been selected. Reference (reference) ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 89 Inverter temperature 20-100 °C 0-20 mA Output frequency higher than f par. 225 (TEMP 20-100 C=0-20 mA) [11] (above frequency low) [11] Inverter temperature 20-100 °C 4-20 mA (TEMP 20-100 C=4-20 mA) [12] ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 90 Pulse current (PULSE CURRENT) [28] Feedback higher than FB , the feedback value is higher than the value Pulse power (PULSE POWER) [29] Warning: Low feedback, FB set in parameter 227 ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 91 Speed-compensated stop (Spd cmp stop) Speed-compensated counter stop with reset (Spd cmp cstop w. res) Only active for speed-compensated stop. Speed-compensated counter stop without reset (Spd cmp cstop no res) ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 92: Parameter Group 4-** Special Functions

    See carry out a reset if there has been a fault in connection with the mains Switching Frequency Special Conditions under failure. Overmodulation function Value: Off (off) ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 93 There are a number of settings for both PID regulators that are made in the same parameters, but selection of regulator type will affect the selections that have to be made in the shared parameters. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 94: Pid Functions

    The differentiator's frequency contribution can therefore be limited in such a way that both a reasonable differentiation ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 95: Handling Of Feedback

    The integral time is the time the integrator Proportional gain indicates how many times the fault (deviation between needs to achieve the same change as the proportional amplification. the feedback signal and the setpoint) is to be amplified. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 96 Set the output voltage (U2) that is to match the second output frequency F2 frequency. (F2), parameter 426 F2 frequency Value: Par. 424 F1 frequency - par. 428 F3 frequency Motor Par. 104 frequency Function: See parameter 423 U1 voltage ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 97 The process regulator will not engage again until either the error is zero or its Disable sign has changed. Select [0] if the integrator is to continue inte- ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 98 The function is activated each time a start command is enabled. For the adjustable frequency drive to be able to 'catch' the ro- ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 99: Serial Communication

    Telegram Profile tocols that can be selected in parameter 512 , are: • Profidrive protocol • Danfoss FC protocol To select Danfoss FC protocol, parameter 512 Telegram Profile is set to FC protocol [1]. 4.7.2 Telegram Traffic Control and response telegrams Content of a character (byte) Telegram traffic in a master-slave SYSTEM is controlled by the master.
  • Page 100 27.5 msec. Bit 0-6 = Frequency converter address 1-126 Bit 0-6 = 0 Broadcast The slave sends the address byte back unchanged in the response tele- gram to the master. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 101 Bits no. 12-15 are used to transfer parameter commands from master to slave and the slave's processed responses back to the master. Text block, which is used to read or write texts via the data block. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 102 To be able to write a text via the PWE block the parameter com- is used as an index. mand (AK) must be set to 'F' Hex. For a write command the text must have the following format: ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 103 EEPROM. Process units PKE = E19F Hex - Write for parameter 416 IND = 0000 Hex = 0000 Hex HIGH = 0014 Hex - Select data option kg/hour [20] ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 104: Control Word According To Fc Protocol

    Bit 04 = '0' causes a stop, in which the motor's speed is ramped down to Bit 00/01 is used to select between the two pre-programmed references Quick stop ramp-down time stop via parameter 212 Preset reference (parameters 215-218 ) according to the following table: ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 105: Status Word According To Fc Profile

    The status word is used to inform the master (e.g. a PC) of the slave's Outside Frequency limit (frequency converter) mode. Slave⇒Master. frequency range Motor running Voltage warn. Current limit Thermal warn. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 106: Fast I/O Fc-Profile

    The input status in the status word reflects the actual input state (High or Low) regardless of the selected digital input function. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 107: Control Word According To Fieldbus Profile

    Used to increase the speed reference by the value in parameter 219 Catch-up/slow-down reference Bit 12 = '0' does not cause any change to the reference. Bit 03, Coasting stop: ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 108: Status Word According To Profidrive Protocol

    Bit 03, No trip/trip: Status word according to FC protocol. See description under Bit 04, ON 2/OFF 2: Bit 04 = '0' means that Bit 01 in the control word = '1'. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 109 = 0 Hz Output frequency high limit Par. 202 = 50 Hz Status word = 0F03 Hex. Output frequency = 2000 Hex ⇒ 50% of the frequency range, corre- sponding to 25 Hz. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 110: Parameter Group 5-** Serial Communication

    '0'. Logic and In the case of [2] the function must also be activated via a digital input. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 111 Dig. input Ser. port Function DC braking Reversing Motor running DC braking Value: Motor running Digital input (DIGITAL INPUT) Serial port (SERIAL PORT) Logic and (LOGIC AND) Logic or (LOGIC OR) ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 112 The function is the same as in parameter 213 Serial communication Setup msb Setup lsb Function Description of choice: Setup 1 Jog frequency f can be selected between 0 Hz and f Setup 2 Setup 3 Setup 4 ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 113 Jogging fre- present value, stop the motor, be frozen at parameter 213 quency Output frequency, high limit f , be frozen at parameter 202 or stop and activate a cut out. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 114 Gives the present power absorbed by the motor in HP. Gives the present control word on the frequency converter in Hex. See Motor voltage, parameter 524: Serial communication for the FCD 300. Gives the voltage being supplied to the motor. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 115 Description of choice: Generally, the value of 100 ms is sufficient for Modbus RTU networks, although some Modbus RTU networks may operate on a timeout value as short as 35 ms. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 116: Parameter Group 6-** Technical Functions

    If a trip occurs, it is possible to see the cause, time and a possible value of the output current or output voltage. Value: No reset (DO NOT RESET) Reset (RESET COUNTER) ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 117 If the LEDs are flashing a code (4 LEDs alternatively), the control card the frequency converter. test has failed (see the section Internal faults for further details. Change Parameter 632 Nameplate: BMC software identification: the control card to start up the frequency converter. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 118 This parameter enables a configuration of a Profibus Control Card. The default value depends on the produced unit, also being the maximum obtainable value. This means, that a control card only can be down gra- ded to a lower performance version. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 119 ® 5 All About FCD 300 Decentral FCD 300 Design Guide ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 120: All About Fcd

    Danfoss has chosen a solution in which the brake resistor is not integrated into the frequency converter. This gives the user the following advantages: The resistor's cycle time can be selected as required.
  • Page 121 ( % ) η motor x η Remember to check that the brake resistance can manage a voltage of 850 Volt, if Danfoss brake resistors are not being used. 420139 η is typically 0.90 and η is typically 0.98. For 400 Volt, R...
  • Page 122 − = The process time in seconds. = The braking time in seconds. Danfoss sells brake resistors with variable duty-cycles up to 40%. For example, with a 10% duty-cycle, brake resistors can take up P in 10% of the peak process period.
  • Page 123 The connection cable to the brake resistor must be screened/armoured. Connect the screen to the conductive backplate at the frequency converter and to the brake resistor metal cabinet by means of cable clamps. If Danfoss brake resistors are not used, it must be ensured that inductance for the brake resistor is low. ®...

  • Page 124: Internal Brake Resistor

    The brake resistor should be fitted to a nonflammable material. For protection of the installation, a thermal relay is fitted that cuts out the frequency converter if the brake current is too high. Danfoss' 40% brake resistors contain a KLIXON switch. Flat pack resistors are self-protecting.
  • Page 125 ® 5 All About FCD 300 Decentral FCD 300 Design Guide 5.1.12 Mechanical Dimensions of Flatpack Brake Resistors 100 W, 200 W ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 126 ® Decentral FCD 300 Design Guide 5 All About FCD 300 5.1.13 Dimensions of Mounting Brackets ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 127: Special Conditions

    PELV isolation of the control card is guaranteed under the following condition: There may be max. 300 V between phase and earth. A motor thermistor connected to terminals 31a-31b must be double isolated to obtain PELV. Danfoss Bauer provides double isolated thermistors. See also the section Diagram in the Design Guide.

  • Page 128: Extreme Operating Conditions

    PEAK 5.2.5 Switching on the Input The waiting time between switching the mains voltage on terminals 91, 92 and 93 must be min. 30 sec. Start up time appr. 2.3 sec. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 129: Acoustic Noise

    The function ensures that the frequency converter automatically adjusts the switch frequency between f and f (parameter 411), see sw,min sw, max drawing below. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 130: Derating For Air Pressure

    The frequency converter has been designed to meet the IEC 68-2-3 standard, EN 50178 item 9.4.2.2/ DIN 40040 class E at 40 °C. Cyclic damp heat IEC 68-2-30. 100% humidity with temperature cycling. 5.2.14 UL Standard This device is UL-approved. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 131: Efficiency

    Some of the harmonic currents might disturb communication equipment connected to the same transformer or cause resonance in connection with power- factor correction batteries. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 132: Power Factor

    FCD 322-335 5 m screened/armoured motor cable For 10 m cable please contact Danfoss. FCD 300 with class 1A RFI-filter is a product of the restricted sales distribution class according to IEC 61800-3. In a domestic environ- ment this product may cause radio interference in which case the user may be required to take adequate measures.

  • Page 133: Aggressive Environments

    LCP2-plug shown on the drawing is installed. The LCP2 is an easy-to -navigate user-friendly interface used to access and adjust all parameters. It displays parameters in six different languages. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 134 Flashing while warning situation is present Green The unit is supplied by mains power or 24 V DC Mains power or 24 V DC is missing Table 5.1: LED diagnostics on decentralised FCD 300 ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 135: Status Messages

    Technical data suitable for the frequency converter, see . When the fre- tinue to run unchanged. If the UDC remains above the voltage warning ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 136 70 °C. The tolerance is ± 5 °C. The temperature Trip delay overcurrent in parameter 409 can be caused by the following: The ambient temperature too high. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 137: Warning Words, Extended Status Words And Alarm Words

    004000 Motor overload 008000 Inverter overload 010000 Undervolt 020000 Overvolt 040000 Phase loss 080000 Live zero error 100000 Heat sink temperature too high 2000000 Profibus communication fault 8000000 Inrush fault 10000000 Internal fault ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 138: General Technical Data

    180% for 0.5 sec. Overload torque (parameter 101 Torque characteristic = Constant torque) 160% Overload torque (parameter 101 Torque characteristic = Variable torque) 160% *Percentage relates to frequency converter's nominal current. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 139 Accuracy (1 kHz - 67.6 kHz) terminal 33 Max. error: 0.1% of full scale The pulse input is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. See section entitled Galvanic Isolation. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 140 Power consumption with/without mains supply <1W/5-12W Reliable galvanic isolation: Full galvanic isolation if the external 24 V DC supply is also of the PELV type. Sensor supply (T63, T73): Terminal nos 201, 202, 203, 204 ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 141 Monitoring of the intermediate circuit voltage ensures that the frequency converter cuts out if the intermediate circuit voltage is too low or too high. • The frequency converter is protected against earth fault on motor terminals U, V, W. ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 142: Available Literature

    Typr gG / gL pre fuses or corrosponding circuit brakers should be used. If you want to maintain UL/cUL branch circuit fuses according to NEC should be used. Alternatively a circuit braker Danfoss type CTI 25 MB or equivalent should be used.

  • Page 143: Factory Settings

    0.01 0.001 0.0001 0.00001 Data type: Data type shows the type and length of the telegram. Data type Description Integer 16 Integer 32 Unsigned 8 Unsigned 16 Unsigned 32 Text string ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 144 0.0 Hz Warn. High frequency 132.0 Hz Warn. Low Feedback -4000.000 Warn. High Feedback 4000.000 Frequency bypass, 0 Hz (OFF) bandwidth Frequency bypass 1 0.0 Hz Frequency bypass 2 0.0 Hz ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 145 Proc. PID diff. ampl. limit Proc. PID lowpass filter time 0.02 s Flying start Not possible Speed PID feedforward factor 100% Controller range 10 % Frequency range monitor Enable Brake voltage reduce ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 146 Nameplate: Communication option type Nameplate: BMC software identification Nameplate: Unit identification for communication Nameplate: Software parts no. Software version BMC software identification Power card identification Configure Control Card Depends on unit type ® MG.90.S1.02 - VLT is a registered Danfoss trademark...

  • Page 147: Index

    Control Word 103, 106 Counter Stop Via Terminal 33 Counter Value Current Limit, Current, Minimum Value Data Character (byte) Data Readout Dc Brake Time Dc Brake Voltage Dc Braking Dc Hold Voltage ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 148 Galvanic Isolation (pelv) Hand Mode Handling Of References Harmonics High Voltage Warning 32, 40 Initialise Internal Fault Jog Frequency Jog Ramp Time Language Lcp 2 Lcp 2 Plug, Optional Lcp Copy Leakage Reactance ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 149 Process Control, Closed Loop Process Pid Process Regulation Process Units Product Standard Profibus Dp-v1 Programming Setup Protection Protocol Protocols Pulse Max. 29 Pulse Max. 33 Pulse Start/stop Quick Menu Setup Quick Menu, Userdefined ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 150 Switch Frequency Switching Frequency Switching On The Input Telegram Profile Telegram Structure Telegram Traffic Temperature-dependent Switch Frequency Terminal 42 Terminal 53 Terminal 60 Terminals 48, 55 Thermal Motor Protection Thermistor Time Out ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 151 ® Index Decentral FCD 300 Design Guide Torque Characteristic U/f-ratio Ul Standard Unit Information Variable Torque Warning Functions Warning Words, Extended Status Words And Alarm Words Warnings/alarm Messages ® MG.90.S1.02 - VLT is a registered Danfoss trademark...
  • Page 152 Below is a list of articles with direct links to our shop Electric Automation Network where you can see: • Quote per purchase volume in real time. • Online documentation and datasheets of all products. • Estimated delivery time enquiry in real time. •...
  • Page 153 178B9186 Buy on EAN VLT® Decentral FCD 300 175N1958 Buy on EAN VLT® Decentral FCD 300 178B2095 Buy on EAN VLT® Decentral FCD 300 178B2091 Buy on EAN VLT® Decentral FCD 300 178B2093 Buy on EAN VLT® Decentral FCD 300 178B2092 Buy on EAN VLT®...
  • Page 154 178B9256 Buy on EAN VLT® Decentral FCD 300 178B9254 Buy on EAN VLT® Decentral FCD 300 178B9225 Buy on EAN VLT® Decentral FCD 300 175N1856 Buy on EAN VLT® Decentral FCD 300 178B5116 Buy on EAN VLT® Decentral FCD 300 178B4024 Buy on EAN VLT®...
  • Page 155 178B2205 Buy on EAN VLT® Decentral FCD 300 178B2206 Buy on EAN VLT® Decentral FCD 300 178B9215 Buy on EAN VLT® Decentral FCD 300 175N1869 Buy on EAN VLT® Decentral FCD 300 178B2308 Buy on EAN VLT® Decentral FCD 300 178B2301 Buy on EAN VLT®...
  • Page 156 175N1919 Buy on EAN VLT® Decentral FCD 300 178B2813 Buy on EAN VLT® Decentral FCD 300 178B3503 Buy on EAN VLT® Decentral FCD 300 178B3505 Buy on EAN VLT® Decentral FCD 300 178B4207 Buy on EAN VLT® Decentral FCD 300 178B3430 Buy on EAN VLT®...

Table of Contents
