mode. In Auto mode the variable frequency drive is
controlled by external signals whereas the variable
frequency drive in Hand mode is controlled via a local
reference directly from the control unit.
Description of choice:
If Not active [0] is selected in this parameter, the Hand
mode function will be inactive. This blocking can be
activated as desired. If Active [1] is selected you can
switch between Auto- and Hand mode.
NOTE
This parameter is only valid for LCP 2.
024 User-defined Quick Menu
(USER QUICK MENU)
Value:
Not active (DISABLE)
Active (ENABLE)
Function:
In this parameter you can select the standard
setup of the Quick menu key on the control panel
and the LCP 2 control panel.
Using this function, in parameter 025 Quick Menu
setup the user can select up to 20 parameters
for the Quick Menu key.
Description of choice:
If not active [0] is selected, the standard setup
of the Quick Menu key is active.
If Active [1] is selected, the user-defined
Quick Menu is active.
025 Quick Menu setup
(QUICK MENU SETUP)
Value:
[Index 1 - 20] Value: 0 - 999
Function:
In this parameter you define which parameters are
required in the Quick Menu when parameter 024
User-defined Quick Menu is set to Active [1] ´ .
Up to 20 parameters can be selected for the
user-defined Quick Menu.
= factory setting. () = display text [] = value for use in communication via serial communication port
106
Decentral Solutions
NOTE
Please note that this parameter can only be set
using an LCP 2 control panel. See Order form.
Description of choice:
The Quick Menu is set up as follows:
1. Select parameter 025 Quick Menu setup
and press [CHANGE DATA].
2. Index 1 indicates the first parameter in Quick
Menu. You can scroll between the index numbers
using the [+ / -] keys. Select Index 1.
3. Using [< >] you can scroll between the
three figures. Press the [<] key once ad
the last number in the parameter number
can be selected using the [+ / -] keys.
Set Index 1 to 100 for parameter 100 Configuration.
4. Press [OK] when Index 1 has been set to 100.
5. Repeat steps 2 - 4 until all parameters required
[0]
have been set to the Quick Menu key.
[1]
6. Press [OK] to complete the Quick Menu setup.
If parameter 100 Configuration is selected at Index
1, Quick Menu will start with this parameter every
time Quick Menu is activated.
Please note that parameter 024 User-defined Quick
Menu and parameter 025 Quick Menu setup are reset
to the factory setting during initialisation.
026
LED Status
(LED STATUS)
Value:
Overload (OVERLOAD)
Therm. warn/alarm 36 (OVERTEMP)
Thermistor/ETR (THERMAL MOTOR)
Digital input 18 (DIGITAL INPUT 18)
Digital input 19 (DIGITAL INPUT 19)
Digital input 27 (DIGITAL INPUT 27)
Digital input 29 (DIGITAL INPUT 29)
000
Digital input 33 (DIGITAL INPUT 33)
As relay par. 323 (AS RELAY / P323)
As dig.outp. par. 341 (AD DIG. OUT. / P341)
As mech.brake output
(AS MECH. BRAKE OUTPUT)
Function:
This parameter enables the user to visualize different
situations using the Status LED.
MG.90.F2.22 - VLT is a registered Danfoss trademark
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
