PC Software tools

PC Software - MCT 10
All drives are equipped with a serial communication
port. We provide a PC tool for communication
between PC and adjustable frequency drive, VLT
Motion Control Tool MCT 10 Set-up Software.
MCT 10 Set-up Software
MCT 10 has been designed as an easy-to-use
interactive tool for setting parameters in our
adjustable frequency drives.
The MCT 10 Set-up Software will be useful for:
• Planning a communication network off-line.
MCT 10 contains a complete adjustable
frequency drive database
• Commissioning adjustable frequency drives on line
• Saving settings for all adjustable frequency drives
• Replacing a drive in a network
• Expanding an existing network
• Future developed drives will be supported
MCT 10 Set-up Software support Profibus DP-V1 via
a Master class 2 connection. It makes it possible to

Accessories for DMS 300 and FCD 300

Type
LCP2 control unit
Cable for LCP2 control
unit
LCP2 remote-mounting
kit
LOP (Local Operation
Pad)
Motor adaption plate
Membrane
Plug kit for LCP2
Motor star terminal
Installation kit
M 12 plug
Viton Gasket
Viton Gasket
Data Cable
Motor mounting adaptor 175N2115
Aluminium plate with holes drilled to fit the FCD/DMS
box. Must be fitted locally for the actual motor.
MG.90.F2.22 - VLT is a registered Danfoss trademark
Description
FCD LCP2 for programming the adjustable frequency
drive
FCD Cable from LCP2 to adjustable frequency drive
FCD Kit for remote-mounting of LCP2 (incl. 39 in.
cable, excl. LCP2)
FCD LOP can be used for setting the reference
and start/stop via the control terminals
DMS/FCD Plate for adapting to non Danfoss Bauer motors
DMS/FCD Membrane for preventing condensation
FCD Plug for LCP2 for mounting in the terminal box.
DMS/FCD Terminal for interconnection of motor wires (star
point)
FCD Installation kit for mounting in panels
FCD E.g. for DeviceNet
FCD 303-315 Painting shop compatible
FCD 322-335 Painting shop compatible
FCD For PC communication
Decentral Solutions
on-line read/write parameters in a adjustable frequency
drive via the Profibus network. This will eliminate the
need for an extra communication network.
The MCT 10 Set-up Software Modules
The following modules are included in the
software package:
MCT 10 Set-up Software
Setting parameters
Copy to and from adjustable frequency
drives
Documentation and print out of
parameter settings incl. diagrams
SyncPos
Creating SyncPos program
Ordering number:
Please order your CD containing MCT 10 Set-up
Software using code number 130B1000.
LCP2 connection 175N2118 (for the FCD
300 series)
Ordering no.
175N0131
175N0162
175N0160
175N0128
175N2115
175N2116
175N2118
175N2119
175N2207
175N2279
175N2431
175N2450
175N2491
29
