3 Components and power supply
3.5.5.2 Configuration using the IP terminal (LAN1..4 connectors)
The Teldat H2 RAIL includes a default configuration, which activates if the device has not been pre-configured.
The router's default configuration sets up the device with the following IP access address and mask:
Note
Some devices leave the factory with customized settings. This personalization may mean that your
router's default configuration is different to the one shown above.
This initial configuration lets you access the router's configuration console through the Telnet IP protocol. To do this,
follow these steps:
• Configure the Ethernet interface on the IP terminal (usually a PC) using an IP address within the following range
[192.168.1.2, 192.168.1.254] and mask 255.255.255.0. For example, 192.168.1.2, 255.255.255.0.
• Connect the IP terminal Ethernet interface to any of the Ethernet switch ports on the Teldat H2 RAIL (LAN1..4
connectors) using an appropriate Ethernet cable (M12 to RJ45).
• Start a Telnet session from the IP terminal to IP address 192.168.1.1 ( Teldat H2 RAIL default address).
• The default configuration does not ask for login credentials (user/password) to access the console.
For further information on how to configure the device, please refer to the user manuals provided by Teldat on the
documentation CD or on the web.
3.6 SIM card installation
The Teldat H2 RAIL is equipped with up to four WWAN interfaces that require SIM cards to operate.
Some carriers in certain countries provide services (CDMA) that do not require SIM cards. However, in routers where
a SIM card is required, at least one must be inserted.
The Teldat H2 RAIL has four SIM trays located on the rear of the device.
SIM allocation depends on the WWAN modules installed and their configuration. For further information about SIM
configuration and assignment, please see the Teldat Dm781-I Cellular Interface manual.
Installed Modules
MOD1
MOD1, MOD2
MOD1, MOD2, MOD3 and
MOD4
Warning
This router is compatible with 1.8 V and 3 V SIM cards. Do not install SIMs that do not support these
voltages.
Never install a SIM card when the device is switched on.
Always disconnect the router from the main power supply before installing a SIM card.
14
• IP Address: 192.168.1.1
• IP Mask: 255.255.255.0
SIM allocation
SIM1 and/or SIM3 (DualSIM option).
For old hardware revisions (0,1,2): SIM1 and/or SIM2.
SIM1 and/or SIM3 can be assigned to MOD1; SIM2 and/or SIM4 can be assigned
to MOD2.
For old hardware revisions (0,1,2): SIM1 to MOD1, SIM2 to MOD2.
One SIM is automatically assigned to each module: SIMx to MODx.
Teldat S.A.
Teldat H2 RAIL
