Receive Sensitivity, 1R.
(tolerance ± 2 dB)
Technology WLAN 802.11a/b/g/n. WPEA-25NI specifications.
Frequency Range
Channel Number
Type of Modulation
Conducted Output Power per
chain, 1T.
(tolerance ± 2 dB)
Teldat H2 RAIL
5GHZ, 802.11ac HT80: +14dBm @MCS9.
802.11a: -80dBm @54Mbps.
802.11bg: -80dBm @54Mbps.
2.4GHz, 802.11gn HT20: -77dBm @MCS7.
2.4GHz, 802.11gn HT40: -75dBm @MCS7.
5 GHz, 802.11an/ac HT20: -71dBm @MCS9.
5GHZ, 802.11n/ac HT40: -71dBm @MCS9.
5GHZ, 802.11ac HT80: -68dBm @MCS9.
a/n ISM Band: 5.150 ~ 5.725 GHz.
b/g/n ISM Band: 2.400 ~ 2.4835 GHz.
2.4 GHz:
802.11b, 802.11g, 802.11n (20MHz): 13.
802.11n (40MHz): 9.
5.0 GHz:
5.18 ~ 5.32 GHz.
802.11a, 802.11n (20MHz): 8.
802.11n (40MHz): 4.
5.50 ~ 5.70 GHz
802.11a, 802.11n (20MHz): 8.
802.11n (40MHz): 3.
2.4 GHz:
802.11b: DSSS
802.11g/n: OFDM.
5.0 GHz:
802.11a/n: OFDM.
Note: The maximum RF power setting will vary according to individual country
regulations.
802.11a: +14dBm @54Mbps.
802.11b: +19dBm @11Mbps.
802.11g: +16dBm @54Mbps.
802.11gn HT20: +15dBm @MCS7.
802.11gn HT40: +14dBm @MCS7.
802.11an HT20: +12dBm @MCS7.
