Bandwidth (802.11n)
Bandwidth (802.11ac)
A.4.5 GPS interface
STANDARDS
SATELLITE CHANNELS
CONNECTOR
ANTENNA
A.4.6 Configuration interface
INTERFACES
PROTOCOLS
SPEED
CONNECTOR
A.4.7 Power
INPUT VOLTAGE
INPUT CURRENT
MAXIMUM POWER
Teldat H2 RAIL
20/40 MHz (bundling two adjoining 20 MHz channels into one 40 MHz channel).
20 MHz; 40 MHz (bundling two adjoining 20 MHz channels into one 40 MHz chan-
nel); 80 MHz (bundling four adjoining 20 MHz channels into one 80 MHz channel)
NMEA.
Maximum 30 channels (16 GPS, 14 GLONASS) simultaneous tracking.
RF FME male.
3.3 V Active.
Passive.
This can be configured in two modes:
Asynchronous Port :
24 DCE. Hardware flow control is not permitted.
Local Console:
V.24 DCE only 8-N-1, without flow control.
Asynchronous Port:
AT, PPP, GPS-DATA.
Asynchronous Port:
300 at 115,200 bps.
Local console:
9,600 bps (configurable up to 115,200).
DB9 female located on the front panel of the device.
Depending on the model:
+110 VDC.
+24 VDC.
Depending on the model:
180 mA @110 VDC or
830 mA @24 VDC.
30 W.
