Technical information
5 GHz Operation
Automatic Rate Selection (ARS) Available.
Transmission rate
Data rates for 802.11b,g (2.4
GHz)
Data rates for 802.11a,h (5
GHz)
Data rates for 802.11n, Long
Guard (800ns), 20 MHz
Data rates for 802.11n, Short
Guard (400ns), 20 MHz
Data rates for 802.11n, Long
Guard (800ns), 40 MHz
Data rates for 802.11n, Short
Guard (400ns), 40 MHz
Data rates for 802.11ac, Long
Guard (800ns), 20 MHz with two
spatial streams
Data rates for 802.11ac, Short
Guard (400ns), 20 MHz with two
spatial streams
Data rates for 802.11ac, Long
Guard (800ns), 40 MHz with two
spatial streams
Data rates for 802.11ac, Short
Guard (400ns), 40 MHz with two
spatial streams
Data rates for 802.11ac, Long
Guard (800ns), 80 MHz with two
spatial streams
Data rates for 802.11ac, Short
Guard (400ns), 80 MHz with two
spatial streams
Output power limitation (without
antenna gain)
26
Automatic.
11, 5.5, 2 and 1 Mbps (DSSS modulation);
54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation)
54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation).
MSC0 6,5 Mbps; MSC1 13 Mbps; MCS2 19,5 Mbps; MCS3 26 Mbps; MCS4 39
Mbps; MSC5 52 Mbps; MCS6 58,5 Mbps; MCS7 65 Mbps; MCS8 13 Mbps; MCS9
26 Mbps; MCS10 39 Mbps; MCS11 52 Mbps; MCS12 78 Mbps; MCS13 104
Mbps; MCS14 117 Mbps; MCS15 130 Mbps.
MSC0 7,2 Mbps; MSC1 14,4 Mbps; MCS2 21,7 Mbps; MCS3 28,9 Mbps; MCS4
43,3 Mbps; MSC5 57,8 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27
Mbps; MCS9 54 Mbps; MCS10 81 Mbps; MCS11 108 Mbps; MCS12 162 Mbps;
MCS13 216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
MSC0 13,5 Mbps; MSC1 27 Mbps; MCS2 40,5 Mbps; MCS3 54 Mbps; MCS4 81
Mbps; MSC5 108 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27 Mbps;
MCS9 54 Mbps; MCS10 81 Mbps; MCS11 108 Mbps; MCS12 162 Mbps; MCS13
216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
MSC0 15 Mbps; MSC1 30 Mbps; MCS2 45 Mbps; MCS3 60 Mbps; MCS4 90
Mbps; MSC5 120 Mbps; MCS6 135 Mbps; MCS7 150 Mbps; MCS8 30 Mbps;
MCS9 60 Mbps; MCS10 90 Mbps; MCS11 120 Mbps; MCS12 180 Mbps; MCS13
240 Mbps; MCS14 270 Mbps; MCS15 300 Mbps.
MSC0 13 Mbps; MSC1 26 Mbps; MCS2 39 Mbps; MCS3 52 Mbps; MCS4 78
Mbps; MSC5 104 Mbps; MCS6 117 Mbps; MCS7 130 Mbps; MCS8 156 Mbps
MSC0 14,4 Mbps; MSC1 28,9 Mbps; MCS2 43,3 Mbps; MCS3 57,8 Mbps; MCS4
86,7 Mbps; MSC5 115,6 Mbps; MCS6 130,3 Mbps; MCS7 144,4 Mbps; MCS8
173,3 Mbps
MSC0 27 Mbps; MSC1 54 Mbps; MCS2 81 Mbps; MCS3 108 Mbps; MCS4 162
Mbps; MSC5 216 Mbps; MCS6 243 Mbps; MCS7 270 Mbps; MCS8 324 Mbps;
MCS9 360 Mbps
MSC0 30 Mbps; MSC1 60 Mbps; MCS2 90 Mbps; MCS3120 Mbps; MCS4 180
Mbps; MSC5 240 Mbps; MCS6 270 Mbps; MCS7 300 Mbps; MCS8 360
Mbps;MCS9 400 Mbps
MSC0 58,5 Mbps; MSC1 117 Mbps; MCS2 175,5 Mbps; MCS3 234 Mbps; MCS4
351 Mbps; MSC5 468 Mbps; MCS6 526,5 Mbps; MCS7 585 Mbps; MCS8 702
Mbps; MCS9 780 Mbps
MSC0 65 Mbps; MSC1 130 Mbps; MCS2 195 Mbps; MCS3 260 Mbps; MCS4 390
Mbps; MSC5 520 Mbps; MCS6 585 Mbps; MCS7 650 Mbps; MCS8 780 Mbps;
MCS9 866,7 Mbps
Adjustable in the following steps: 5, 8,11,14,16 dBm and maximum. Maximal
power varies depending on data rate, frequency band and country setting.
