CE Radio information
Band 8
Technology UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+. MC7430 Specifications.
Bands
Band 1
Band 8
B.2 WLAN specifications
WLAN modules provide WLAN connectivity.
This product is supplied without antennas. The choice of antennas is left to the discretion of the operator, who is re-
sponsible for ensuring they comply with local regulations.
Technology WLAN 802.11a/b/g/n/ac. WLE600VX specifications.
Frequency Range
Channel Number
Type of Modulation
Conducted Output
Power per chain, 1T.
(tolerance ± 2 dB)
30
Tx: 880–915 MHz
Rx: 925–960 MHz
Frequencies
Tx: 1920–1980 MHz
Rx: 2110–2170 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
802.11b/g/n-HT20: 2412 ~ 2472MHz;
802.11n-HT40: 2422 ~ 2462MHz;
802.11a /n-HT20/ac-VHT20: 5180~5240 MHz, 5260~5320 MHz, 5500~5700 MHz;
802.11n-HT40/ac-VHT40: 5190~5230 MHz, 5270~5310 MHz, 5510~5670 MHz;
802.11ac-VHT80: 5210 MHz, 5290 MHz, 5530 MHz, 5610 MHz.
802.11a/n-HT20/ac-VHT20: 19
802.11n-HT40/ac-VHT40: 9
802.11ac-VHT80: 4
2.4 GHz:
802.11b: DSSS
802.11g/n: OFDM.
5.0 GHz:
802.11a/n/ac: OFDM.
Note: The maximum RF power setting will vary according to individual country regula-
tions.
802.11a: +17dBm @54Mbps.
802.11bg: +18dBm @54Mbps.
2.4GHz, 802.11gn HT20: +16dBm @MCS7.
2.4GHz, 802.11gn HT40: +16dBm @MCS7.
5 GHz, 802.11an/ac HT20: +15dBm @MCS9.
5GHZ, 802.11n/ac HT40: +14dBm @MCS9.
+23 dBm ± 1 dB
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
