Display mode - selection of read-out state

There are three options in connection with the
choice of read-out state in the Display mode - I, II
and III. The choice of read-out state determines the
number of operating variables read out.
Read-out state: I:
Line 1 Description for
operating variable
in line 2
The table below gives the units linked to the
variables in the first and second line of the
display (see parameter 009).
Operating variable:
Reference
Reference
Feedback
Frequency
Frequency x scaling
Motor current
Torque
Power
Power
Motor voltage
DC-link voltage
FC thermal
Hours run
Input status, dig. Input
External reference
Status word
Heat sink temp.
Alarm word
Control word
Warning word 1
Warning word 2
Analog input 1
Analog input 2
*) Select in parameter 416. The unit is shown in readout state 1 line 1
otherwise 'U' is shown.
Operating variables 1,1 and 1,2 and 1,3 in the first
line, and operating variable 2 in the second line are
selected via parameter 009, 010, 011 and 012.
26
SETUP
1
II: III:
Data value for Description for
3 operating 3 operating
variables in line variables in line
1 1
Unit:
[%]
[unit]*
[unit]*
[Hz]
[-]
[A]
[%]
[kW]
[HP]
[V]
[V]
[%]
[Hours]
[Binary code]
[%]
[Hex]
[ºC]
[Hex]
[Hex]
[Hex]
[Hex]
[mA]
[V]
®
VLT FCM Series
• Read-out state I:
This read-out state is standard after starting
up or after initialisation.
FREQUENCY
50.0 Hz
MOTOR IS RUNNING
Line 2 gives the data value of an operating variable with
related unit, and line 1 provides a text which explains
line 2, cf. table. In the example, Frequency has
been selected as variable via parameter 009. During
normal operation another variable can immediately
be read out by using the [+/-] keys.
•
Read-out state II:
Switching between read-out states I and II is effected
by pressing the [DISPLAY / STATUS] key.
24.3% 30.2% 13.8A
50.0 Hz
MOTOR IS RUNNING
In this state, data values for four operating values
are shown at the same time, giving the related
unit, cf. table. In the example, Reference, Torque,
Current and Frequency are selected as variables
in the first and second line.
• Read-out state III:
This read-out state can be held as long as the
[DISPLAY/STATUS] key is pressed. When the key is
released, the system switches back to Read-out state
II, unless the key is pressed for less than approx. 1 sec.
REF% TORQUE CURR A
50.0 Hz
MOTOR IS RUNNING
This is where parameter names and units for
operating variables in the first line are given -
operating variable 2 remains unchanged.
