Parameter
No. Name and Description
25
[M-S Input]
Configures the I/O Data to be transferred from the
network to the drive.
Default
26
[M-S Output]
Configures the I/O Data to be transferred from the
drive to the network.
Default
27
[Ref Adjust]
Percent scale factor for the Reference from the
Network.
Bit
7 6
5
4
3
2
1
x
x x
0
0
0
0
Bit
7 6
5
4
3
2
1
x
x x
0
0
0
0
Configuring the Adapter
Details
Default:
Bit Values:
Type:
Reset Required:
Bit Definitions
0
0 = Cmd/Ref
1
1 = Datalink A
2 = Datalink B
3 = Datalink C
4 = Datalink D
5 = Not Used
6 = Not Used
7 = Not Used
Default:
Bit Values:
Type:
Reset Required:
Bit Definitions
0
0 = Cmd/Ref
1
1 = Datalink A
2 = Datalink B
3 = Datalink C
4 = Datalink D
5 = Not Used
6 = Not Used
7 = Not Used
Default:
Minimum:
Maximum:
Type:
Reset Required:
3-9
xxx0 0001
0 = I/O disabled
1 = I/O enabled
Read/Write
Yes
xxx0 0001
0 = I/O disabled
1 = I/O enabled
Read/Write
Yes
100.00
0.00
200.00
Read/Write
No
