Configuring The Adapter; Configuration Tools - Allen-Bradley PowerFlex 20-comm-c FRN 1. Series User Manual

Configuring the Adapter

Chapter 3 provides instructions and information for setting the
parameters in the adapter.
Topic

Configuration Tools

Using the PowerFlex HIM
Setting the Node Address
Setting the I/O Configuration
Selecting Master-Slave
For a list of parameters, refer to
definitions of terms in this chapter, refer to the Glossary.
Configuration Tools
The ControlNet adapter stores parameters and other information in its
own non-volatile memory. You must, therefore, access the adapter to
view and edit its parameters. The following tools can be used to access
the adapter parameters:
Tool
DriveExplorer Software (version 2.01
or higher)
DriveExecutive Software (version 1.01
or higher)
PowerFlex HIM
Page Topic
3-1 Selecting Reference Adjust
3-2 Setting a Fault Action
3-3 Resetting the Adapter
3-3 Viewing the Adapter Configuration
3-4
Appendix B,
Refer To:
DriveExplorer Getting Results Manual ,
Publication 9306-GR001B-EN-E (Download
Only), or the online help
DriveExecutive Online Help
page 3-2
Chapter
Adapter Parameters. For
3
Page
3-5
3-6
3-7
3-8
