PLC-5C Applications
Figure 5.3 I/O Messaging (Continued)
0002
0003
0004
0005
0006
Operator
Clear Faults
Pushbutton
I:000
2
Operator
Fwd / Rev
Selector Switch
I:000
3
Operator
Fwd / Rev
Selector Switch
I:000
3
Drive
READY
Status
Bit
N9:0
0
Drive
ACTIVE
Status
Bit
N9:0
1
Drive
Logic Command
CLEAR FAULTS
N10:0
3
Drive
Logic Command
FORWARD
N10:0
4
Drive
Logic Command
REVERSE
N10:0
5
Operator
Drive Ready
Status
Display
O:000
0
Operator
Drive Active
Status
Display
O:000
1
