Register Object
Instance Attributes
Attribute Access Rule Name
ID
1 Get
2 Get
3 Get
4 Conditional
(1)
The access rule of Set is optional if attribute 2, Direction = 1. If Direction = 0, the access rule is
Get.
Important: Setting a register object attribute can only be accomplished
Service Code
0x0E
0x10
(Continued)
Data Type Description
Bad Flag BOOL
Direction BOOL
Size UINT
(1)
Data ARRAY of
BITS
through a connection with a non-zero control timeout
attribute.
Implemented for:
Class
Yes
Yes
ControlNet Objects
If set to 1, then attribute 4 may contain
invalid, bad or otherwise corrupt data.
0 = good
1 = bad
Direction of data transfer
0 = Producer Register (Drive to ControlNet)
1 = Consumer Register (ControlNet to Drive)
Size of register data in bits
Data to be transferred
Service Name
Instance
Yes Get_Attribute_Single
Yes Set_Attribute_Single
C-5
