A Set_Attribute_Single message is used to write a single parameter
(Figure
5.9).
• A Service Code of "10" indicates the Set_Attribute_Single service
(see
Page
C-19,
• An Instance Number of "41" indicates Drive Parameter 41 will be
accessed (see
Page
• An Attribute Number of "9" indicates the Parameter Value Attribute
will be written (see
Figure 5.9 CIO Set Attribute Single Screen
Set Attribute Single example request (writing PowerFlex 70 Parameter
41 in Figure 5.9):
Request Data
N13:0
2300
Common Services
C-16, Instances).
Page
C-17,
Instance
Value = 230.0VAC
PLC-5C Applications
).
Attributes).
5-19
