C-4 ControlNet Objects

Register Object

Class Code
Hexadecimal Decimal
0x07
Instances
Instance
1
2
3
4
5
6
7
8
9
10
11
12
13
14
(1)
The mask command word is set to the value of the first word of the data where
there are ones in the second word of the data. Command = (word 1 and not
word 2) or (word 1 and word 2). This only controls specified bits in the Logic
Command data to the DPI product and does not change the Reference value.
Class Attributes
Attribute Access Rule Name
ID
100 Set
7
Description
All I/O data being read from the DPI device (read-only)
All I/O data written to the DPI device (read/write)
Logic Status and Feedback data (read-only)
Logic Command and Reference data (read/write)
Datalink A (input data from device to scanner) (read only)
Datalink A (output data from scanner to device) (read/write)
Datalink B (input data from device to scanner) (read only)
Datalink B (output data from scanner to device) (read/write)
Datalink C (input data from device to scanner) (read only)
Datalink C (output data from scanner to device) (read/write)
Datalink D (input data from device to scanner) (read only)
Datalink D (output data from scanner to device) (read/write)
Logic Status and Feedback Data (read-only)
(1)
Mask (read/write)
Control Timeout UINT
Data Type Description
Control timeout in seconds
