RSNetWorx Configuration for PLC-5C Applications
6. If the On-line / Off-line Mismatch dialog box appears, click OK to
use the on-line data
( Figure 4.17).
Figure 4.16 Online / Offline Mismatch Dialog Box
Figure 4.17
Note: During the save process, RSNetWorx will execute the browse
function. Allow RSNetWorx to complete the browse (1-99 nodes), even
if you already see the entire network. Canceling the browse early may
cause an improper scheduling of I/O.
7. Right-click on the controller's icon (PLC-5C) and select SCANlist
Configuration. The Scanlist Configuration screen
used to configure the controller to communicate with the nodes.
(Figure 4.16). If prompted to save, save the data
4-11
(Figure 4.18), is
