Figure 6.21 I/O Messaging (Continued)
This rung moves data from the DriveReference tag to the drive where it is used as a frequency reference.
This rung moves data from the DriveReference tag to the drive where it is used as a frequency reference.
7
This rung moves Datalink data from the drive.
This rung moves Datalink data from the drive.
8
This rung moves Datalink data to the drive.
This rung moves Datalink data to the drive.
9
(End)
ControlLogix Applications
COP
Copy File
Source
DriveReference
Dest DriveOutputImage.Data[1]
<PowerFlex70_02:O.Data[1]>
Length
COP
Copy File
Source
DriveInputImage.Data[4]
<PowerFlex70_02:I.Data[4]>
Dest ParameterDataFromDrive[0]
Length
COP
Copy File
Source
ParameterDataToDrive[0]
Dest
DriveOutputImage.Data[2]
<PowerFlex70_02:O.Data[2]>
Length
6-17
1
8
8
